Cadillac SRX I (2003-2009) tac motor ctrl 1 cmp exhaust bank 2 fuel inj 3 ctrl Wiring diagram

5 VOLT REF 3 5 VOLT REF LOW REF 5-VOLT REF 2 APPROXIMATELY 35 CM (13.8 IN) FROM BRN WIRE BRN/WHT WIRE CAMSHAFT POSITION (CMP) SENSOR EXHAUST BANK 1 (AT FRONT OF LEFT CYLINDER HEAD) CAMSHAFT POSITION (CMP) SENSOR EXHAUST BANK 2 (AT FRONT OF RIGHT CYLINDER HEAD) CAMSHAFT POSITION (CMP) SENSOR INTAKE BANK 1 (AT FRONT OF LEFT CYLINDER HEAD) CAMSHAFT POSITION (CMP) SENSOR INTAKE BANK 2 (AT FRONT OF RIGHT CYLINDER HEAD) CMP SENS INTAKE 1 CMP SENS INTAKE 2 CMP SENS EXHAUST 1 CKP SENS 1 SIG CRANKSHAFT POSITION (CKP) SENSOR (AT LOWER RIGHT REAR OF ENGINE) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT SIDE OF ENGINE) FUEL INJ 5 CTRL FUEL INJ 6 CTRL EVAP CANISTER PURGE GENERATOR FIELD DUTY GRY WIRE IMRC SOLENOID CTRL LOW REF KS 1 SIG KS 2 SIG OIL PRESSURE SENS SIG LOW REF LOW REF LOW REF 5 VOLT REF 3 LOW REF LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK/BLK WIRE PPL PPL 20 21 22 PPL CMP SENS EXHAUST 2 GENERATOR TURN ON SIG PPL IC 1 CTRL IC 3 CTRL IC 5 CTRL PPL/WHT WIRE STARTING/CHARGING SYSTEM TAC MOTOR CTRL 1 CMP EXHAUST BANK 2 FUEL INJ 3 CTRL TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK CONNECTOR WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
