Cadillac SRX I (2003-2009) shift lock solenoid ctrl Wiring diagram
This page shows the only wiring diagram for the component.shift lock solenoid ctrl, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock solenoid ctrl (1 of 1)
4.6L 3.6L
5-VOLT REFERENCE
A/T SHIFT LOCK CONTROL SOLENOID
AUTOMATIC TRANSMISSION SHIFT LOCK ACTUATOR
BATTERY
BCM 2 FUSE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (ECM) (ON LOWER LEFT SIDE OF DASH)
GRY WIRE
HI SPD GMLAN SERIAL DATA
HI SPD GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
LOW REFERENCE
LT GRN WIRE
RED/WHT WIRE
SHIFT LOCK SOLENOID CTRL
STOP LAMP SW SIG
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
Go to component -> Shift interlock circuit -> SHIFT LOCK SOLENOID CTRL
