Cadillac SRX I (2003-2009) serial data low spd gmlan Wiring diagram

1-6 AUDIO AMPLIFIER (AT LEFT REAR QUARTERPANEL, BARE BEHIND TRIM PANEL) BLK LT BLU/ WIRE BLK LT GRN/ WIRE BLK WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) BRN WIRE CENTER CONSOLE SPEAKER COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE DK BLU/ WHT WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE GRY WIRE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (BEHIND STEERING WHEEL) LEFT D PILLAR SPEAKER LEFT REAR DOOR SPEAKER LEFT STEERING WHEEL CONTROLS LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NAVIGATION SYSTEM NOISE COMPENSATION MICROPHONE (IN OVERHEAD CONSOLE) ON "D" PILLAR) ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL PPL SUPPLY VOLT REAR SUBWOOFER SPEAKER COIL 1 COIL 2 RED/BLK WIRE REMOTE ENABLE SIGNAL RIGHT D PILLAR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT STEERING WHEEL CONTROLS SEEK DN SEEK UP VOL DN VOL UP SERIAL DATA LOW SPD GMLAN SOURCE MUTE STEERING WHEEL CONTROL SIG SUPPLY VOLTAGE DRAIN WIRE TAN WIRE TAN/BLK WIRE VOICE REC WHT WIRE WHT/RED WIRE YEL WIRE
