Cadillac SRX I (2003-2009) rear window washer pump control wiring diagram
This page shows the only wiring diagram for the component.rear window washer pump control, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear window washer pump control wiring diagram (1 of 1)
ACCESSORY RELAY
ACCESSORY VOLTAGE
ACCY WPR FUSE
AJAR SW LIFTGATE LATCH (LOWER CENTER OF LIFTGATE)
BLK WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
DK GRN WIRE
FUSE
GROUND
GRY WIRE
HOT AT ALL TIMES
LIFTGATE AJAR SW POWER LIFTGATE MODULE (IN LEFT REAR QUARTERPANEL)
LIFTGATE AJAR SW SIG
LT GRN WIRE
ORG/BLK WIRE
POWER DISTRIBUTION SYSTEM
REAR WASH FUSE
REAR WASH RELAY
REAR WINDOW WASHER FLUID PUMP (NEAR BASE OF WASHER FLUID RESERVOIR)
REAR WINDOW WASHER PUMP CONTROL
REAR WINDOW WIPER MOTOR (AT CENTER OF LIFTGATE)
REAR WINDOW WIPER SWITCH SIGNAL
REAR WIPER/WASHER SWITCH
RIGHT REAR FUSE BLOCK
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
WIPE DELAY WIPE WASH OFF
YEL WIRE
Go to component -> Rear wiper/washer circuit -> REAR WINDOW WASHER PUMP CONTROL
