Cadillac SRX I (2003-2009) malfu- nction ind lamp Wiring diagram
This page shows the only wiring diagram for the component.malfu- nction ind lamp, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram malfu- nction ind lamp (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CANISTER VENT FUSE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FUEL PUMP
GMLAN GMLAN IGN 1 B+ LOGIC INSTRUMENT PANEL CLUSTER (IPC)
GRY WIRE
HOT AT ALL TIMES
IC 1 CTRL LOW REF
IGN 1 VOLT
IGN 1 VOLT LOW REF IC 3 CTRL
IGN 1 VOLT LOW REF IC 7 CTRL
IGNITION COIL/MODULE 1 (AT TOP FRONT OF RIGHT CYLINDER HEAD)
IGNITION COIL/MODULE 3 (AT TOP CENTER OF RIGHT CYLINDER HEAD)
IGNITION COIL/MODULE 5 (AT TOP CENTER OF RIGHT CYLINDER HEAD)
IGNITION COIL/MODULE 7 (AT TOP REAR OF RIGHT CYLINDER HEAD)
IGNITION SWITCH
LOGIC
LOGIC LOGIC
LOW REF IGN 1 VOLT IC 5 CTRL
LT BLU WIRE
LT GRN WIRE
MALFU- NCTION IND LAMP
NCA WIRE
OFF LOCK
PNK PPL 16 17 18 19 20 21 22 23 24 25 26 WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL 8 9 10 11 12
PPL/WHT WIRE
RED/WHT WIRE
RIGHT FUEL LEVEL SENSOR
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
RUN WIRE
SPARK PLUG
TAN WIRE
TAN/WHT WIRE
WHT WIRE
Go to component -> Wiring diagram engine performance 4.6l vin a (2 of 5) -> MALFU- NCTION IND LAMP
