Cadillac SRX I (2003-2009) logic ground Wiring diagram

ANTENNA PRESENT SIGNAL BATTERY POSITIVE VOLTAGE BATTERY POSITIVE VOLTAGE K-BUS BLK WIRE BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH) BRN WIRE CLOSE SHADE DIMMING DK BLU WIRE DK GRN WIRE FRONT SUNSHADE CONTROL MODULE (UNDER HEADLINER, IN BACK OF FRONT SUNROOF) GROUND GROUND IGNITION 3 VOLTAGE GRY WIRE HOT AT ALL TIMES IGNITION 3 VOLTAGE K- BUS LOGIC LOGIC GROUND LT BLU WIRE LT GRN WIRE OPEN SHADE ORG/ WIRE PPL PPL SUNSHADE SW EXPRESS SIG REAR SUNSHADE CONTROL MODULE (UNDER HEADLINER, BETWEEN FRONT, REAR SUNROOF) REAR SUNSHADE SWITCH RED/WHT WIRE RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET) ROOF CLOSE ROOF EXPRESS ROOF OPEN SHADE CLOSE SHADE EXPRESS SHADE OPEN SUNROOF CONTROL MODULE (UNDER HEADLINER, IN BACK OF FRONT SUNROOF) SUNROOF MOD FUSE SUNROOF SW CLOSE SIG SUNROOF SW EXPRESS SIG SUNROOF SW OPEN SIG SUNROOF/FRONT SUNSHADE SWITCH SUNSHADE SW CLOSE SIG SUNSHADE SW OPEN SIG SUNSHADE SWITCH CLOSE SIGNAL SUNSHADE SWITCH OPEN SIGNAL SUP VOL WHT WIRE YEL WIRE
