Cadillac SRX I (2003-2009) license light Wiring diagram
This page shows the only wiring diagram for the component.license light, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license light (1 of 1)
AUXILIARY POWER OUTLET- CENTER CONSOLE 1
AUXILIARY POWER OUTLET- CENTER CONSOLE 2
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CIGAR LIGHTER
DIGITAL RADIO RECEIVER AUDIO AMPLIFIER
FRONT PASSENGER DOOR LATCH ASSEMBLY
FRONT PASSENGER DOOR MODULE (FPDM)
FRONT PASSENGER INFLATABLE RESTRAINT PRESENCE SYSTEM (PPS) SENSOR
FRONT PASSENGER WINDOW MOTOR
GRND
LEFT BACK-UP LAMP
LICENSE LIGHT
LIFTGATE COURTESY LAMP
NCA WIRE
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SWITCH
POWER LIFT GATE MODULE LEFT TAIL LAMP ASSEMBLY
RADIO
REAR HEADLAMP LEVELING SENSOR
REAR OBJECT SENSOR CONTROL MODULE
REAR SEAT AUDIO MODULE
REAR VIDEO DISPLAY
REAR WINDOW DEFOGGER GRID
REAR WINDOW WIPER MOTOR
RIGHT BACK-UP LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
SPARE RELAY
TRAFFIC INFORMATION RECEIVER TV TUNER MODULE
TRAILER PROVISIONS
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ 5-BAND, DIGITAL AUDIO
W/ 8-WAY POWER PASSENGER ADJUSTER SEAT
W/ AUTOMATIC HEADLAMP CONTROL LEVELING SYSTEM
W/ NAVIGATION
W/ ONSTAR
W/ PREMIUM AUDIO SYSTEM
W/ REAR SEAT ENTERTAINMENT
W/ TRAILER PROVISIONS
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> LICENSE LIGHT
