Cadillac SRX I (2003-2009) lh turn rh turn off auto Wiring diagram
This page shows the only wiring diagram for the component.lh turn rh turn off auto, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh turn rh turn off auto (1 of 1)
16 15 1415 1414 RH TURN SW SIG LH TURN SW SIG
2 17 1 19 5356 18 RR ST/TN SUP VOLT LH LP OUT DET SIG LR ST/TN SUP VOLT
4.6L 3.6L
5365 5365 3340 (BLUNT CUT)
6 SPEED A/T 5 SPEED A/T
8 10 301 2144 PARK LP SW SIG HAZARD SW SIG
ASSEMBLY) (3.6L: LEFT FRONT SIDE OF ENGINE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLUNT CUT)
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE
GRY WIRE
HAZARD SWITCH
HEAD
HOT AT ALL TIMES
HOT W/ IGN MAIN RELAY ENERGIZED
IGN 1 VOLT
LEFT FRONT TURN SIGNAL LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET)
LEFT TURN SIG IND
LH DRL TN SUP VOLT PARK LAMP SUP VOLT STOP LAMP SUP VOLT 24 5
LH POS PRK LAMP RELAY
LH TURN RH TURN OFF AUTO
LO SPD SERIAL DATA
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
MARKER LAMP FUSE
PARK
PNK WIRE
PPL
PPL RH LP OUT DET SIG
PRK LAMP LH POS
RED WIRE
RED/WHT WIRE
RELAY/ FUSE
RH DRL TN SUP VOLT BAT POS VOLT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT TURN SIG IND
RVC SNSR
SERIAL DATA
ST SW SIG
STOP LAMP SW SIG
TAN WIRE
TO LEFT REAR FUSE BLOCK LH PARK FUSE (DIAGRAM 2 OF 2)
TRANSMISSION CONTROL MODULE (TCM) (AT RIGHT FRONT OF ENGINE COMPT)
TURN SIGNAL/ MLTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) AIR BAG FUSE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LH TURN RH TURN OFF AUTO
