Cadillac SRX I (2003-2009) lh pos prk lamp relay Wiring diagrams
This page contains all the electrical diagrams for the component. lh pos prk lamp relay, in which he is found in the car Cadillac SRX I (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
lh pos prk lamp relay wiring diagram (1 of 2)
16 15 1415 1414 RH TURN SW SIG LH TURN SW SIG
2 17 1 19 5356 18 RR ST/TN SUP VOLT LH LP OUT DET SIG LR ST/TN SUP VOLT
4.6L 3.6L
5365 5365 3340 (BLUNT CUT)
6 SPEED A/T 5 SPEED A/T
8 10 301 2144 PARK LP SW SIG HAZARD SW SIG
ASSEMBLY) (3.6L: LEFT FRONT SIDE OF ENGINE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLUNT CUT)
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE
GRY WIRE
HAZARD SWITCH
HEAD
HOT AT ALL TIMES
HOT W/ IGN MAIN RELAY ENERGIZED
IGN 1 VOLT
LEFT FRONT TURN SIGNAL LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET)
LEFT TURN SIG IND
LH DRL TN SUP VOLT PARK LAMP SUP VOLT STOP LAMP SUP VOLT 24 5
LH POS PRK LAMP RELAY
LH TURN RH TURN OFF AUTO
LO SPD SERIAL DATA
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
MARKER LAMP FUSE
PARK
PNK WIRE
PPL
PPL RH LP OUT DET SIG
PRK LAMP LH POS
RED WIRE
RED/WHT WIRE
RELAY/ FUSE
RH DRL TN SUP VOLT BAT POS VOLT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT TURN SIG IND
RVC SNSR
SERIAL DATA
ST SW SIG
STOP LAMP SW SIG
TAN WIRE
TO LEFT REAR FUSE BLOCK LH PARK FUSE (DIAGRAM 2 OF 2)
TRANSMISSION CONTROL MODULE (TCM) (AT RIGHT FRONT OF ENGINE COMPT)
TURN SIGNAL/ MLTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) AIR BAG FUSE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LH POS PRK LAMP RELAY
lh pos prk lamp relay wiring diagram (2 of 2)
AMP FUSE
APO FUSE
AUDIO AMPLIFIER
BLK WIRE
DIGITAL RADIO RECEIVER (W/ DIGITAL RADIO)
DRIVER DOOR MODULE (DDM)
DRIVER DR MOD FUSE
DRIVER WINDOW MOTOR
ELC FUSE
ELC RELAY
FOLDING SEAT RECLINE SWITCH REAR FOLDING SEAT STOW SWITCH
FROM LPDB 1 FUSE (DIAGRAM 3 OF 8)
FROM LPDB 2 FUSE (DIAGRAM 3 OF 8)
FRONT FOLDING SEAT STOW SWITCH
LEFT REAR WINDOW MOTOR PASSENGER WINDOW MOTOR
LH POS PRK LAMP RELAY
MEMORY RPA FUSE
MEMORY SEAT MODULE (MSM)
MODULE
ONSTAR TV/XM FUSE
PRK LAMP LH POS RELAY FUSE
PWR WNDWS CIRCUIT BREAKER
REAR AUXILIARY POWER OUTLET
REAR OBJECT SENSOR CONTROL MODULE
REAR SEAT AUDIO REAR VIDEO DISPLAY
REAR SEAT MODULE
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR WINDOW MOTOR
RSA/ RSE FUSE
RSM FUSE
SPARE FUSE
SPARE RELAY
SU/RFA FUSE
TV TUNER MODULE (W/ INFOTAINMENT SYSTEM, 007, 008)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (W/ ONSTAR)
W/ FLEXIBLE REAR SEAT CONFIGURATION
W/ MEMORY
W/ REAR SEAT ENTERTAINMENT PACKAGE
W/O FLEXIBLE REAR SEAT CONFIGURATION
WHT WIRE
Go to component -> Power distribution circuit (6 of 8) -> LH POS PRK LAMP RELAY
