Cadillac SRX I (2003-2009) left headlamp leveling actuator ign 1 volt Wiring diagram
This page shows the only wiring diagram for the component.left headlamp leveling actuator ign 1 volt, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlamp leveling actuator ign 1 volt (1 of 1)
AIR QUALITY SENSOR (AQS) (W/ AUTO RECIRCULATING AIR FILTER)
ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FRONT HEADLAMP LEVELING SENSOR (IN LEFT FRONT WHEEL HOUSING)
GRN WIRE
GROUND
GRY WIRE
HEADLAMP LEVELING IGN 1 SWITCH 1 SIGNAL VOLT
HEADLAMP LEVELING SWITCH 1 SIGNAL
HOT AT ALL TIMES
IGN MAIN RELAY
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP LEVELING ACTUATOR IGN 1 VOLT
LEFT HEATED WASHER NOZZLE (AT LEFT SIDE OF HOOD)
MISC IGN FUSE
NCA WIRE
PNK IGN 1 VOLTAGE WIRE
PNK PNK WIRE
PNK WIRE
REAR HEADLAMP LEVELING SENSOR (IN LEFT REAR WHEEL HOUSING)
RIGHT HEADLAMP
RIGHT HEADLAMP LEVELING ACTUATOR SERIAL DATA
RIGHT HEATED WASHER NOZZLE (AT RIGHT SIDE OF HOOD)
SERIAL DATA
THEFT DETERRENT ALARM SIREN (REAR OF RIGHT SHOCK TOWER)
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
Go to component -> Headlamps leveling circuit -> LEFT HEADLAMP LEVELING ACTUATOR IGN 1 VOLT
