Cadillac SRX I (2003-2009) (in rear fascia harness, approximately 38 cm Wiring diagram
This page shows the only wiring diagram for the component.(in rear fascia harness, approximately 38 cm, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in rear fascia harness, approximately 38 cm (1 of 1)
1 2 3 4 5 6 BATTERY POS VOLT TELTALE ASSEMBLY SPLY VOLT
BLK WIRE
CENTER AMBER IND CTRL
CENTER AMBER INDICATOR CONTROL
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
INDICATOR CONTROL
LEFT AMBER IND CTRL
LEFT AMBER INDICATOR CONTROL
LEFT REAR CORNER OBJECT SENSOR
LEFT REAR FUSE BLOCK
LEFT REAR MIDDLE OBJECT ALARM SENSOR
LOW REF
LOW SPEED GMLAN SERIAL DATA
MEMORY RPA FUSE
ORG/ WIRE
PPL SIGNAL
REAR OBJECT SENSOR CONTROL MODULE (IN LEFT REAR QUARTERPANEL AREA)
REAR PARKING ASSIST DISPLAY
RED IND CTRL WIRE
RED WIRE
RED/WHT WIRE
RIGHT REAR CORNER OBJECT ALARM SENSOR (AT RIGHT SIDE OF REAR BUMPER)
RIGHT REAR MIDDLE OBJECT ALARM SENSOR
SIGNAL
SUPPLY VOLT
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> (IN REAR FASCIA HARNESS, APPROXIMATELY 38 CM
