Cadillac SRX I (2003-2009) (in engine poa harness, approximately 30 cm pnk/ Wiring diagram
This page shows the only wiring diagram for the component.(in engine poa harness, approximately 30 cm pnk/, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in engine poa harness, approximately 30 cm pnk/ (1 of 1)
3.6L
4.6L
BANK 1 SENSOR 1
BANK 2 SENSOR 1
BANK 2 SENSOR 1 BANK 1 SENSOR 1
BLK WIRE
CMP ACTUATOR SOLENOID EXHAUST BANK 1
CMP ACTUATOR SOLENOID EXHAUST BANK 2
CMP ACTUATOR SOLENOID INTAKE BANK 1
CMP ACTUATOR SOLENOID INTAKE BANK 2
ECM 1 FUSE
EMISSION 1 FUSE
ENGINE CONTROL MODULE
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE SOLENOID VALVE
EVEN COILS FUSE
FROM PWR/TRN RELAY (DIAGRAM 1 OF 8)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL INJECTOR 5
FUEL INJECTOR 6
FUEL INJECTOR 7
FUEL INJECTOR 8
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
IGNITION COIL 1 FUEL INJECTOR 3 FUEL INJECTOR 5 IGNITION COIL 3
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION COIL/ MODULE 2 IGNITION COIL/ MODULE 4
IGNITION COIL/ MODULE 3 IGNITION COIL/ MODULE 1 IGNITION COIL/ MODULE 5
IGNITION COIL/ MODULE 6
IGNITION COIL/ MODULE 7
IGNITION COIL/ MODULE 8
INTAKE MANIFOLD RUNNER CONTROL (IMRC) SOLENOID
NCA WIRE
ODD COILS FUSE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
UNDERHOOD FUSE
Go to component -> Power distribution circuit (2 of 8) -> (IN ENGINE POA HARNESS, APPROXIMATELY 30 CM PNK/ WIRE
