Cadillac SRX I (2003-2009) ignition lock cyl solenoid ctrl Wiring diagram
This page shows the only wiring diagram for the component.ignition lock cyl solenoid ctrl, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition lock cyl solenoid ctrl (1 of 1)
5-VOLT REFERENCE
AUTOMATIC TRANSMISSION SHIFT LEVER
BATTERY
BCM 2 FUSE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL)
COMPUTER DATA LINES
DK BLU WIRE
GRY WIRE
HI SPD GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
IGNITION LOCK CYL SOLENOID CTRL
IGNITION LOCK CYLINDER CONTROL SWITCH
IGNITION LOCK CYLINDER SOLENOID (AT RIGHT SIDE OF STEERING COLUMN)
LOW REFERENCE
LT GRN WIRE
PPL/WHT WIRE
RED/WHT WIRE
STOP LAMP SW SIG
SYSTEM
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
