Cadillac SRX I (2003-2009) hot w/ ign main relay energized Wiring diagrams

AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION SHIFT LEVER CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DK GRN WIRE ECM, TCM IGN FUSE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED IGN VOLT LINE PRESSURE CONTROL (PC) SOLENOID LINE PRESSURE CTRL SOLENOID LOW REF PC SOLENOID 2 CTRL PC SOLENOID 3 CTRL PC SOLENOID 4 CTRL PC SOLENOID 5 CTRL PNK WIRE POWER DISTRIBUTION SYSTEM PPL PRESSURE CONTROL (PC) SOLENOID 2 PRESSURE CONTROL (PC) SOLENOID 3 PRESSURE CONTROL (PC) SOLENOID 4 PRESSURE CONTROL (PC) SOLENOID 5 PRESSURE CONTROL (PC) SOLENOID, TORQUE CONVERTER CLUTCH (TCC) RED/WHT WIRE SHIFT SOLENOID (SS) 1 SHIFT SOLENOID (SS) 2 SS 1 CTRL SS 2 CTRL TAP UP/TAP DOWN SWITCH TCC, PC SOLENOID CTRL TCM BATT FUSE TFP SW 1 VOLT TFP SW 3 VOLT TFP SW 4 VOLT TFP SW 5 VOLT TFT SENS SIG TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION FLUID PRESSURE (TFP) SWITCH TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)

4 3 PPL A/C CMPRSR CLUTCH RELAY AC CLTCH FUSE BATTERY POS VOL LOW REFERENCE GROUND BLK WIRE BLK/WHT WIRE BLOWER FUSE BLOWER MOTOR SPEED CTRL BLOWER RELAY BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) BRN WIRE DEFOGGER SYSTEM COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DK PNK WIRE EMISSION 2 FUSE GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED HOT W/ PWR/TRN RELAY ENERGIZE HVAC CONTROL MODULE (CENTER OF DASH, UNDER RADIO) IGNITION 3 VOLTAGE LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MISC IGN FUSE NCA WIRE NEAR BASE OF STEERING COIL) PNK WIRE PPL/WHT WIRE RECIRCULATION ACTUATOR (LEFT OF BLOWER MOTOR ON HVAC) RED/WHT WIRE SUNLOAD/ AMBIENT LIGHT SENSOR (AT TOP CENTER OF DASH) TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) DISPLAY FUSE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

16 15 1415 1414 RH TURN SW SIG LH TURN SW SIG 2 17 1 19 5356 18 RR ST/TN SUP VOLT LH LP OUT DET SIG LR ST/TN SUP VOLT 4.6L 3.6L 5365 5365 3340 (BLUNT CUT) 6 SPEED A/T 5 SPEED A/T 8 10 301 2144 PARK LP SW SIG HAZARD SW SIG ASSEMBLY) (3.6L: LEFT FRONT SIDE OF ENGINE) BLK WIRE BLK/WHT WIRE BLU WIRE BLUNT CUT) BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE FUSE GRY WIRE HAZARD SWITCH HEAD HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED IGN 1 VOLT LEFT FRONT TURN SIGNAL LAMP LEFT LICENSE LAMP RIGHT LICENSE LAMP LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET) LEFT TURN SIG IND LH DRL TN SUP VOLT PARK LAMP SUP VOLT STOP LAMP SUP VOLT 24 5 LH POS PRK LAMP RELAY LH TURN RH TURN OFF AUTO LO SPD SERIAL DATA LOGIC INSTRUMENT PANEL CLUSTER (IPC) LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE MARKER LAMP FUSE PARK PNK WIRE PPL PPL RH LP OUT DET SIG PRK LAMP LH POS RED WIRE RED/WHT WIRE RELAY/ FUSE RH DRL TN SUP VOLT BAT POS VOLT RIGHT FRONT TURN SIGNAL LAMP RIGHT TURN SIG IND RVC SNSR SERIAL DATA ST SW SIG STOP LAMP SW SIG TAN WIRE TO LEFT REAR FUSE BLOCK LH PARK FUSE (DIAGRAM 2 OF 2) TRANSMISSION CONTROL MODULE (TCM) (AT RIGHT FRONT OF ENGINE COMPT) TURN SIGNAL/ MLTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) AIR BAG FUSE WHT WIRE YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PNK WIRE 21 22 23 24 25 26 PPL 5234 2307 2308 WARNING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM ABS IND. AIR BAG FUSE AIR BAG IND AIR BAG ON IND CTRL AIR BAG OFF IND CTRL BACKLIGHTING CTRL BATT POS VOLT IGN 1 VOLT BCM 7/ CLOCK FUSE BLK/WHT WIRE BRAKE IND BRAKE WARN IND CTRL BRN WIRE BRN/WHT WIRE CHARGING IND CLASS 2 (ECM) B+ COMPUTER DATA LINES SYSTEM CRUISE IND SERIAL DATA (ECM) DIC SELECT MENU SW SIG DIC SW SIG LOW REF DISPLAY FUSE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE IND FOG LAMPS IND FUEL LEVEL GAUGE GMLAN SERIAL GMLAN SERIAL GROUND HIGH BEAM IND HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED ILLUMINATION INSTRUMENT PANEL CLUSTER (IPC) LEFT TURN IND LOGIC LOW TIRE PRESSURE IND (NOT USED) MALFUNCTION IND MESSAGE CENTER MESSAGE REQUEST OIL LEVEL IND LAMP PARK LAMP IND VSC IND PASS SEAT BELT IND CTRL PNK WIRE RED WIRE RED/WHT WIRE RIGHT TURN IND SEAT BELT IND SECURITY IND SERIAL DATA SERIAL DATA (EBCM) SERIAL DATA (ECM) SERIAL DATA (RIM) SERIAL DATA (SDM) SERIAL DATA IPC SPEEDOMETER SPEEDOMETER CONTROL SPLICE PACK TACHOMETER TACHOMETER CONTROL B+ TAN WIRE TAN/WHT WIRE TEMPERATURE GAUGE TOW/HAUL IND TRIP RESET SW SIG TRIP RESET SWITCH TRIP/ODOMETER CTRL TRIP/ ODOMETER UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) WASHER FLUID LEVEL SIG WHT WIRE WIPER/WASHER SYSTEM

1 2 3 4 BATTERY POS VOLT LO SPD GMLAN SERIAL DATA 13 14 LO SPD GMLAN SERIAL DATA LO SPD GMLAN SERIAL DATA 5 7 (W/O ANTI-THEFT) (W/ ANTI-THEFT) 8 12 PARK LAMP ON SW SIG HEADLAMPS ON SIG 9 11 LO SPD GMLAN SERIAL DATA LEFT FRONT DOOR OPEN SW SIG AIR BAG FUSE AUTO HEAD BLK WIRE BLK/BLU WIRE BLK/TAN WIRE BLK/WHT WIRE BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH) BRN/WHT WIRE CLOSED OPEN COAX COMPUTER DATA LINES SYSTEM DK GRN WIRE DRIVER DOOR LATCH ASSEMBLY (REAR OF DRIVER'S DOOR) AJAR DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR PANEL) GROUND HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED IGN DATA IGN SW FUSE IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) KEY IN IGNITION SW SIG KEY-IN SWITCH KEYLESS ENTRY/ TIRE PRESSURE ANTENNA KEYLESS ENTRY/ TIRE PRESSURE ANTENNA SIGNAL LEFT FRONT TIRE PRESSURE MONITOR SENSOR LEFT REAR FUSE BLOCK LEFT REAR TIRE PRESSURE MONITOR SENSOR RIGHT REAR TIRE PRESSURE MONITOR SENSOR LEFT REAR WINDOW ANTENNA ASSEMBLY (ON LEFT REAR QUARTER GLASS) LEFT SEAT BELT SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) LO SPD GMLAN SERIAL DATA LOGIC LOW IGN SPEED GMLAN SERIAL SEAT BELT IND DATA LOW SERIAL DATA LT GRN WIRE OFF ORG/ WIRE PARK OFF PARK OFF AUTO HEAD PASSENGER AIR BAG IND PASSENGER SEAT BELT IND PASSENGER SEAT BELT IND CTRL PNK WIRE POWER DISTRIBUTION SYSTEM PPL RADIO RED WIRE RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (IN RIGHT REAR QUARTERPANEL) RIGHT FRONT TIRE PRESSURE MONITOR SENSOR RUN WIRE SERIAL DATA SOLID STATE SOLID STATE SOLID STATE SPEED GMLAN SERIAL SUPPLEMENTAL RESTRAINTS SYSTEM SW/RFA FUSE TIRE PRESSURE IND TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) W/ FLEXIBLE REAR SEAT CONFIGURATION WHT WIRE

30 31 32 33 PNK WIRE 34 35 PPL AIR BAG FUSE BANK 1 SENSOR 2 (DOWNSTREAM OF RIGHT CATALYTIC CONVERTER) BANK 2 SENSOR 2 (DOWNSTREAM OF LEFT CATALYTIC CONVERTER) BLK WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM BATT FUSE ECM FUSE ECM, TCM IGN FUSE EMISSION 1 FUSE EMISSION 2 FUSE EVEN COILS FUSE FUEL PUMP RELAY GRY WIRE GRY/WHT WIRE HEATED OXYGEN HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED IGN 1 INSTRUMENT PANEL CLUSTER (IPC) KNOCK SENSOR (KS) 1 (AT RIGHT SIDE OF ENGINE) KNOCK SENSOR (KS) 2 (AT LEFT SIDE OF ENGINE) LOGIC B+ LOW REF IAT SENS SIG GMLAN LT BLU WIRE LT BLU/WHT WIRE MAF SENS SIG 12 VOLT REF GND MALFUNCTION INDICATOR LAMP MASS AIR FLOW (MAF) SENSOR (IN AIR CLEANER INTAKE TUBE) NCA WIRE ODD COILS FUSE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE PWR/TRN RELAY RED/WHT WIRE SPARE FUSE TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) FUEL PUMP FUSE WHT WIRE YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PPL IC 1 CTRL 5 VOLT REF 2 5 VOLT REF 1 5 VOLT REF 1 LOW REF LOW REF A/C COMPRESSOR CLUTCH HI SPD COOLING FAN EVAP CANISTER VENT ACC WAKE UP SERIAL IGN 1 VOLT B+ PNK WIRE ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) AIR CONDITIONING SYSTEM COOLING FANS SYSTEM APP SENS 1 SIG FUEL TANK PRESSURE APP SENS 2 SIG BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ECM BATT FUSE ECM 1 FUSE ODD COILS FUSE SPARE FUSE ECM, TCM IGN FUSE AIR BAG FUSE EMISSION 1 FUSE EMISSION 2 FUSE EVEN COILS FUSE FUEL LEVEL PRIMARY FUEL LEVEL SECONDARY GRY WIRE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED KNOCK SENSOR (KS) 1 (AT MIDDLE OF RIGHT CYLINDER HEAD, UNDER INTAKE MANIFOLD) KNOCK SENSOR (KS) 2 (AT MIDDLE OF LEFT CYLINDER HEAD, UNDER INTAKE MANIFOLD) KS 2 SIG KS 2 SIG KS 1 SIG KS 1 SIG LOW REF LT BLU WIRE MAIN RLY CTRL MIL CTRL FUEL PUMP RLY CTRL NCA WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE PWR/TRN RELAY RED/WHT WIRE STARTER RLY CTRL STARTING/ CHARGING SYSTEM STOP LP SW SIG TAN WIRE TAN/BLK WIRE TAN/WHT WIRE THROTTLE ACTUATOR CONTROL (TAC) MODULE (AT FRONT OF ENGINE) UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
