Cadillac SRX I (2003-2009) headlamp wash relay Wiring diagrams
This page contains all the electrical diagrams for the component. headlamp wash relay, in which he is found in the car Cadillac SRX I (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
headlamp wash relay wiring diagram (1 of 2)
Go to component -> Headlamp washer circuit -> HEADLAMP WASH RELAY
headlamp wash relay wiring diagram (2 of 2)
A/C CLUTCH FUSE
A/C CMPRSR CLTCH RELAY
ACCY RELAY
ACCY VOL
ACCY WPR FUSE
BCM 7/ CLOCK FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
CLOCK
FOG LAMP RELAY
FRNT WASHER RELAY
FROM PWR/TRN RELAY (DIAGRAM 1 OF 8)
FUEL PUMP FUSE
FUEL PUMP RELAY
HEADLAMP WASH CIRCUIT BREAKER
HEADLAMP WASH RELAY
HI BEAM RELAY
HORN FUSE
HORN RELAY
IGN SW FUSE
INSIDE REAR VIEW MIRROR (ISRVM)
LO BEAM/ HID RELAY
LPDB 1 FUSE 50 LPDB 2 FUSE 50
REAR WASH FUSE
REAR WASH RELAY
REAR WINDOW WIPER MOTOR
RED WIRE
RIGHT WPR/ REAR ISRVM/ FUSE VICS BLOCK FUSE
RPDB 1 FUSE 50
RPDB 2 FUSE 50
SYSTEM, 007
TO ELC FUSE (DIAGRAM BODY CONTROL MODULE (BCM) 8 OF 8)
TO STRTR FUSE (DIAGRAM 4 OF 8)
TO THEFT UGDO/RFA (DIAGRAM 7 OF 8)
TO TO LEFT REAR RSM FUSE (DIAGRAM FUSE BLOCK (DIAGRAM 6 OF 8) 6 OF 8)
TRAFFIC INFORMATION RECEIVER REAR WIPER/ WASHER SWITCH
W/ INFOTAINMENT
WHT WIRE
WPR FUSE
WPR HI RELAY
WPR RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 8) -> HEADLAMP WASH RELAY
