Cadillac SRX I (2003-2009) from driver seat horizontal position sensor) Wiring diagram
This page shows the only wiring diagram for the component.from driver seat horizontal position sensor), which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from driver seat horizontal position sensor) (1 of 1)
AUTOMATIC TRANSMISSION SHIFT LEVER
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
BLK WIRE
BLUNT CUT)
BODY CONTROL MODULE (BCM)
CLOCK
DATA LINK CONNECTOR (DLC)
DIMMER SWITCH
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR MODULE (DDM)
DRIVER INFORMATION CENTER (DLC) SWITCH
DRIVER REAR VIEW OUTSIDE MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER WINDOW MOTOR
FROM DRIVER SEAT HORIZONTAL POSITION SENSOR)
HAZARD SWITCH
INFLATABLE RESTRAINT I/P MODULE INDICATOR
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC) HVAC CONTROL MODULE
LEFT FOOTWELL COURTESY LAMP
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LEFT STEERING WHEEL CONTROLS
MEMORY SEAT MODULE (MSM)
NCA WIRE
PRNDL LAMP
RIGHT FOOTWELL COURTESY LAMP
RIGHT STEERING WHEEL CONTROLS
THEFT DETERRENT CONTROL MODULE
TOW/HAUL SWITCH
TRACTION CONTROL SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ 8-WAY POWER PASSENGER ADJUSTER SEAT
W/ TRAILER PROVISIONS
W/O 8-WAY POWER PASSENGER ADJUSTER SEAT
WHT WIRE
Go to component -> Ground distribution circuit (4 of 4) -> FROM DRIVER SEAT HORIZONTAL POSITION SENSOR)
