Cadillac SRX I (2003-2009) dic sw sig low ref Wiring diagram
This page shows the only wiring diagram for the component.dic sw sig low ref, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dic sw sig low ref (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PNK WIRE
21 22 23 24 25 26 PPL
5234 2307 2308 WARNING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
ABS IND.
AIR BAG FUSE
AIR BAG IND
AIR BAG ON IND CTRL AIR BAG OFF IND CTRL
BACKLIGHTING CTRL
BATT POS VOLT IGN 1 VOLT
BCM 7/ CLOCK FUSE
BLK/WHT WIRE
BRAKE IND
BRAKE WARN IND CTRL
BRN WIRE
BRN/WHT WIRE
CHARGING IND
CLASS 2 (ECM) B+
COMPUTER DATA LINES SYSTEM
CRUISE IND SERIAL DATA (ECM)
DIC SELECT MENU SW SIG
DIC SW SIG LOW REF
DISPLAY FUSE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE IND
FOG LAMPS IND
FUEL LEVEL GAUGE
GMLAN SERIAL GMLAN SERIAL
GROUND
HIGH BEAM IND
HOT AT ALL TIMES
HOT W/ IGN MAIN RELAY ENERGIZED
ILLUMINATION
INSTRUMENT PANEL CLUSTER (IPC)
LEFT TURN IND
LOGIC
LOW TIRE PRESSURE IND (NOT USED)
MALFUNCTION IND
MESSAGE CENTER
MESSAGE REQUEST
OIL LEVEL IND LAMP
PARK LAMP IND VSC IND
PASS SEAT BELT IND CTRL
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT TURN IND
SEAT BELT IND
SECURITY IND
SERIAL DATA
SERIAL DATA (EBCM)
SERIAL DATA (ECM)
SERIAL DATA (RIM)
SERIAL DATA (SDM)
SERIAL DATA IPC
SPEEDOMETER
SPEEDOMETER CONTROL
SPLICE PACK
TACHOMETER
TACHOMETER CONTROL B+
TAN WIRE
TAN/WHT WIRE
TEMPERATURE GAUGE
TOW/HAUL IND
TRIP RESET SW SIG
TRIP RESET SWITCH
TRIP/ODOMETER CTRL TRIP/ ODOMETER
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
WASHER FLUID LEVEL SIG
WHT WIRE
WIPER/WASHER SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> DIC SW SIG LOW REF
