Cadillac SRX I (2003-2009) computer data lines system 2500 1212 Wiring diagram

AUTOMATIC LEVEL AUTO RELAY CTRL BLK WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM 2500 1206 COMPUTER DATA LINES SYSTEM 2500 1212 DATA COMMUNICATION ENABLE SIGNAL DATA SIGNAL BATTERY VOLTAGE DK GRN WIRE ELC MRRTD FUSE FUSE ELC RELAY ELECTRONIC BRAKE CONTROL MODULE (EBCM) (AT RIGHT FRONT CORNER OF ENGINE COMPT) FRAME TO CONTROL ARM) GMLAN SER DATA - GMLAN SER DATA + SENSOR LOW REF RR DAMPER CTRL GMLAN SER DATA - GMLAN SER DATA + SENSOR LOW REF SENSOR LOW REF GRN WIRE HOT AT ALL TIMES LEFT FRONT SUSPENSION DAMPER (TOP OF LEFT FRONT SHOCK) LEFT FRONT SUSPENSION POSITION SENSOR (IN LEFT FRONT WHEEL WELL AREA, FROM LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET) ELC FUSE LEFT REAR SUSPENSION DAMPER (TOP OF LEFT REAR SHOCK) LF POSITION SENS RF POSITION SENS RR POSITION SENS LR DAMPER CTRL LR DAMPER LOW REF RF DAMPER LOW REF LF DAMPER LOW REF LR POSITION SENS LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE PPL PPL RR DAMPER LOW REF 1006 1448 1050 RF DAMPER CTRL LF DAMPER CTRL GROUND PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT SUSPENSION DAMPER (TOP OF RIGHT FRONT SHOCK) RIGHT FRONT SUSPENSION POSITION SENSOR (IN RIGHT FRONT WHEEL WELL AREA, FROM RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET) RIGHT REAR SUSPENSION DAMPER (TOP OF RIGHT REAR SHOCK) SENSOR LOW REF TAN WIRE TAN/BLK WIRE TAN/WHT WIRE VOLTAGE REFERENCE VOLTAGE REFERENCE VOLTAGE REFERENCE VOLTAGE REFERENCE WHT WIRE WHT/BLK WIRE YEL WIRE
