Cadillac SRX I (2003-2009) center console 1 auxiliary power outlet Wiring diagram
This page shows the only wiring diagram for the component.center console 1 auxiliary power outlet, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center console 1 auxiliary power outlet (1 of 1)
3.6L 4.6L
ABS IGN FUSE
AIR BAG FUSE
AIR QUALITY SENSOR (AQS)
AUTOMATIC TRANSMISSION
AUX OUTLET FUSE
BLK WIRE
BLUNT CUT)
BODY CONTROL MODULE (BCM)
CENTER CONSOLE 1 AUXILIARY POWER OUTLET
CENTER CONSOLE 2 AUXILIARY POWER OUTLET
CIG FUSE
CIGAR LIGHTER
ECM, TCM IGN FUSE
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM) INSTRUMENT PANEL CLUSTER (IPC)
FOG LAMP RELAY
FROM ACCY RELAY (DIAGRAM 3 OF 8)
IGN MAIN RELAY
IGN MAIN RELAY COIL CONTROL
LEFT HEATED WASHER NOZZLE RIGHT HEATED WASHER NOZZLE
MASS AIR FLOW (MAF SENSOR)
MISC IGN FUSE
PNK FRONT HEADLAMP LEVELING SENSOR (IF EQUIPPED) WIRE
PNK PNK 3.6L WIRE
PNK PNK 4.6L WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
REAR HEADLAMP LEVELING SENSOR
RED WIRE
RIGHT HEADLAMP LEVELING ACTUATOR LEFT HEADLAMP LEVELING ACTUATOR
STRTR FUSE
STRTR RELAY
THEFT DETERRENT ALARM SIREN
TO BCM 6 FUSE (DIAGRAM 5 OF 8)
TO SPARE FUSE
TRANSMISSION CONTROL MODULE
TRLR BT FUSE
W/ AUTO RECIRCULATING AIR, FILTER
W/ AUTOMATIC HEADLAMP LEVELING CONTROL SYSTEM
W/ PREMIUM AUDIO BRANDED, SURROUND AMPLIFIER SPEAKER SYSTEM
WHT WIRE
Go to component -> Power distribution circuit (4 of 8) -> CENTER CONSOLE 1 AUXILIARY POWER OUTLET
