Cadillac SRX I (2003-2009) body pass through grommet) wiring diagram
This page shows the only wiring diagram for the component.body pass through grommet), which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
body pass through grommet) wiring diagram (1 of 1)
ABS IND.
BLK/WHT WIRE
BODY PASS THROUGH GROMMET)
BRAKE IND
BRK FLUID LVL SENS SIGNAL
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
IGN
IGN 1 VOLTAGE
INSTRUMENT PANEL CLUSTER
LEFT FRONT WHEEL SPEED SENSOR (WSS) (BEHIND LEFT FRONT WHEEL, ON INSIDE OF HUB)
LEFT REAR WHEEL SPEED SENSOR (WSS) (BEHIND LEFT REAR WHEEL, ON INSIDE OF HUB)
LOGIC
LOW SPD SERIAL DATA
LT BLU WIRE
ORG/ WIRE
PNK WIRE
RADIO
RIGHT REAR WHEEL SPEED SENSOR (WSS) (BEHIND RIGHT REAR WHEEL, ON INSIDE OF HUB)
SERIAL DATA
SERIAL DATA LOW SPD
TAN WIRE
TAN/WHT WIRE
VEH SPD SIG
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> BODY PASS THROUGH GROMMET)
