Cadillac SRX I (2003-2009) acc wake up serial ign 1 volt b+ pnk Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PPL IC 1 CTRL 5 VOLT REF 2 5 VOLT REF 1 5 VOLT REF 1 LOW REF LOW REF A/C COMPRESSOR CLUTCH HI SPD COOLING FAN EVAP CANISTER VENT ACC WAKE UP SERIAL IGN 1 VOLT B+ PNK WIRE ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) AIR CONDITIONING SYSTEM COOLING FANS SYSTEM APP SENS 1 SIG FUEL TANK PRESSURE APP SENS 2 SIG BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ECM BATT FUSE ECM 1 FUSE ODD COILS FUSE SPARE FUSE ECM, TCM IGN FUSE AIR BAG FUSE EMISSION 1 FUSE EMISSION 2 FUSE EVEN COILS FUSE FUEL LEVEL PRIMARY FUEL LEVEL SECONDARY GRY WIRE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED KNOCK SENSOR (KS) 1 (AT MIDDLE OF RIGHT CYLINDER HEAD, UNDER INTAKE MANIFOLD) KNOCK SENSOR (KS) 2 (AT MIDDLE OF LEFT CYLINDER HEAD, UNDER INTAKE MANIFOLD) KS 2 SIG KS 2 SIG KS 1 SIG KS 1 SIG LOW REF LT BLU WIRE MAIN RLY CTRL MIL CTRL FUEL PUMP RLY CTRL NCA WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE PWR/TRN RELAY RED/WHT WIRE STARTER RLY CTRL STARTING/ CHARGING SYSTEM STOP LP SW SIG TAN WIRE TAN/BLK WIRE TAN/WHT WIRE THROTTLE ACTUATOR CONTROL (TAC) MODULE (AT FRONT OF ENGINE) UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
