Cadillac SRX I (2003-2009) 9 7 dr unlock rly ctrl dr lock rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.9 7 dr unlock rly ctrl dr lock rly ctrl, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 7 dr unlock rly ctrl dr lock rly ctrl (1 of 1)
14 15 16 RT RR DR AJAR SW SIG LT RR DR AJAR SW SIG DR OPEN SW SIG
24 18 PARK LAMP SUPPLY VOLTAGE HORN RLY CTRL
9 7 DR UNLOCK RLY CTRL DR LOCK RLY CTRL
AJAR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLK WIRE
DOOR LOCK FUSE
EXTERIOR LIGHTS SYSTEM HORNS SYSTEM
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
IGN
INSTRUMENT PANEL CLUSTER (IPC)
JOINT CONNECTOR
LEFT REAR DOOR LATCH ASSEMBLY (REAR OF LEFT REAR DOOR)
LOCK
LOCK RELAY
LOGIC
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
RED WIRE
RIGHT REAR DOOR LATCH ASSEMBLY (REAR OF RIGHT REAR DOOR)
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
SECURITY INDICATOR
SERIAL DATA
TAN WIRE
UNLOCK
UNLOCK RELAY
WHT WIRE
Go to component -> Power door locks circuit (2 of 2) -> 9 7 DR UNLOCK RLY CTRL DR LOCK RLY CTRL
