Cadillac SRX I (2003-2009) 4 10 5 7 vert position sens sig low ref horiz position sens sig wiring diagram
This page shows the only wiring diagram for the component.4 10 5 7 vert position sens sig low ref horiz position sens sig, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
4 10 5 7 vert position sens sig low ref horiz position sens sig wiring diagram (1 of 1)
1 2 MIRROR MTR EXTEND MIRROR MTR RETRACT
1 6 2 MIRROR MTR VERT CTRL RT COM CTRL MIRR MTR MIRROR MTR HORIZ CTRL
4 10 5 7 VERT POSITION SENS SIG LOW REF HORIZ POSITION SENS SIG
5 14 MEMORY SEAT SW SIG
BACKLIGHT
BATTERY
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DOWN
DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR PANEL)
DRIVER DR MOD FUSE
DRIVER OUTSIDE REARVIEW MIRROR
ELECTRO- CHROMIC
EXIT
FOLD
FOLDING MOTOR
GRY WIRE
GRY/BLK WIRE
HEATED MIRROR ELEMENT
HORIZ MOTOR
HORIZ POS SENSOR
HOT AT ALL TIMES
LEFT
LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET)
LOGIC LOGIC
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
MEMORY SEAT SWITCH
MIRRORS SYSTEM
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PDM FUSE
PNK WIRE
RED/WHT WIRE
RIGHT
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
UNFOLD LEFT
VERT MOTOR
VERT POS SENSOR
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> 4 10 5 7 VERT POSITION SENS SIG LOW REF HORIZ POSITION SENS SIG
