Cadillac SRX I (2003-2009) 2500 2501 computer data lines system 1164 1161 1271 1274 1162 1272 Wiring diagram

2 3 4 PNK IGNITION LOW SPD SERIAL DATA LOW SPD SERIAL DATA WIRE 2500 2501 COMPUTER DATA LINES SYSTEM 1164 1161 1271 1274 1162 1272 42 55 HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA - 5-VOLT REFERENCE ABS FUSE ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) AIR BAG FUSE B+ SERIAL DATA (ECM) BATTERY BCM 2 FUSE BLK WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL) BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH CRUISE CTRL SW SIG CRUISE INDICATOR DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (AT RIGHT FRONT CORNER OF ENGINE COMPT) ENGINE CONTROL MODULE (ECM) (LEFT FRONT SIDE OF ENGINE) GRY WIRE HI SPD GMLAN SERIAL DATA BUS + HOT AT ALL TIMES HOT IN RUN OR START IGN MAIN RELAY INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW REFERENCE LT BLU WIRE LT GRN WIRE NCA WIRE PNK 12 VOLT REF WIRE PNK IGN 1 VOLT WIRE PNK WIRE PPL R/A PNK ON OFF WIRE RADIO RED/WHT WIRE STOP LAMP SW SIG TAN WIRE TAN/BLK WIRE THROTTLE ACTUATOR CONTROL (TAC) MODULE (AT TOP FRONT OF ENGINE) THROTTLE ACTUATOR CONTROL (TAC) MOTOR THROTTLE POSITION (TP) SENSOR TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT) VEHICLE SPEED SIG VEHICLE SPEED SIGNAL WHT/BLK WIRE YEL WIRE
