Cadillac SRX I (2003-2009) 1 9 2 10 high serial data low serial data ground switch power Wiring diagram
This page shows the only wiring diagram for the component.1 9 2 10 high serial data low serial data ground switch power, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 9 2 10 high serial data low serial data ground switch power (1 of 1)
1 2 3 4 5 6 7 8 9 10 NAV SER DATA HIGH NAV SER DATA LOW
1 9 2 10 HIGH SERIAL DATA LOW SERIAL DATA GROUND SWITCH POWER
ACCESSORY VOLT GROUND SWITCH POWER GROUND
BARE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COAX
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
RADIO
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
RIGHT REAR WINDOW ANTENNA MODULE (ON RIGHT HEADLINER REAR QUARTER WINDOW)
TRAFFIC INFORMATION RECEIVER (RIGHT REAR OF QUARTER TRIM PANEL)
VICS FM SIGNAL
WPR/ISRVM VICS FUSE
YEL WIRE
Go to component -> Traffic information receiver circuit -> 1 9 2 10 HIGH SERIAL DATA LOW SERIAL DATA GROUND SWITCH POWER
