Cadillac Seville IV (1992-1997) Pass-key circuit

1995 VFTC 4.9L NORTHSTAR BLK/WHT WIRE BULB TEST CRANKING FUEL ENABLE INPUT DK BLU WIRE DK GRN WIRE ENGINE COMPARTMENT FUSE BLOCK FUEL ENABLE FUSE GROUND HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IGNITION KEY IGNITION KEY LOCK CYLINDER IGNITION SWITCH INHIBIT OUTPUT INSTRUMENT CLUSTER KEY RES IN (HI) KEY RES IN (LO) LOCK OFF ORG/ WIRE PASS-KEY DECODER MODULE (IN RIGHT ELECTRONICS BAY, MOUNTED ON BOARD) PNK IGN WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF I/P) PPL PPL/WHT WIRE RESISTOR PELLET RUN WIRE SECURITY IND CTRL SECURITY INDICATOR STARTER ENABLE CTRL STARTER ENABLE RELAY (NEAR FRONT EDGE OF LEFT ROCKER PANEL CHANNEL) STARTER INHIBIT IN STARTER SOLENOID TRUNK COMPARTMENT FUSE BLOCK WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
