VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

SERVICE PARTS IDENTIFICATION LABEL

This label specifies the vehicle's VIN, wheelbase, paint information, and a list of all production options and special equipment. It is located either inside the spare tire cover or inside the trunk lid.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN CODE ID EXPLANATION. Scheme 1

Scheme 1: VIN CODE ID EXPLANATION
Scheme 1: VIN CODE ID EXPLANATION

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

TRANSAXLE SERVICE

Change automatic transmission fluid and filter every 15,000 miles.

Scheme 2

Scheme 2: SERVICE POINT LOCATIONS
Scheme 2: SERVICE POINT LOCATIONS

SERVICE LABOR TIMES

Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

WHEEL & TIRE SPECIFICATIONS

Wheel and tire information can be found on the decal located on the rear of the driver's door or door pillar.

WHEEL TIGHTENING

Wheel lug nuts should be tightened to 100 ft. lbs. (136 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

ANTI-LOCK BRAKE SYSTEM (ABS)

CAUTIONNever mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C); Ethylene-Glycol -35° F (-37°C) - 263° F (128°C).
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

SPARK PLUGS

Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.

TRACTION CONTROL SYSTEM (IF EQUIPPED)

CAUTIONIf tires are allowed to spin at high speeds when TRACTION OFF light is on, tires can explode. Also, spinning the tires with the warning light on can cause the transaxle to overheat. DO NOT spin wheels above 35 MPH.

WARRANTY INFORMATION

CAUTIONAlways refer to customer's copy of warranty information for specific model application and/or owner limitations.

BUMPER-TO-BUMPER PLUS LIMITED WARRANTY (CADILLAC)

The complete vehicle (except tires, battery and damage due to owner negligence) is covered for 4 years or 50,000 miles, whichever occurs first. After the first year or 12,000 miles, repairs are subject to a 25 deductible per repair visit (100 per repair visit for 1989 models). Maintenance items are covered up to their first scheduled replacement interval only.

SUPPLEMENTAL COVERAGE (CADILLAC)

Upon expiration of the Bumper to Bumper Plus Limited Warranty, and subject to a 25 deductible per repair visit, repairs of all parts and assemblies on the entire vehicle as manufactured by Cadillac are covered for 7 years or 100,000 miles, whichever occurs first. Routine maintenance items, such as brake linings, spark plugs and filters, and damage due to misuse of vehicle are not covered.

SUPPLEMENTAL INFLATABLE RESTRAINT WARRANTY

Covers supplemental restraint system (if equipped) for 3 years, regardless of mileage.

CORROSION WARRANTY

Any body-sheet metal panel that is perforated due to corrosion is covered for 6 years or 100,000 miles whichever occurs first.

EMISSIONS DEFECT WARRANTY/PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION PERFORMANCE WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSION DEFECT WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

FUSE PANEL LOCATION

The fuse block is located to the left of the steering column under the dashboard, behind a carpeted cover on the right side of the dash, behind a panel inside the glove box in the trunk compartment or in the engine compartment. For fuse application on models not shown in illustrations, refer to the Fuse Usage Chart on back of fuse panel cover.

UNDERHOOD FUSE PANEL IDENTIFICATION (1992 ELDORADO)

Note. See inside fuse panel cover for fuse and circuit breaker identification.

Scheme 3

Scheme 3: UNDERHOOD FUSE PANEL IDENTIFICATION (1992 ELDORADO)
Scheme 3: UNDERHOOD FUSE PANEL IDENTIFICATION (1992 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp DISTR Electronic Spark Timing (EST) Distributor
  2. 2 - 20 Amp SIR DERM, Arming Sensor
  3. 3 - 10 Amp PCM (IGN) Pass-Key Decoder Module
  4. 4 - 10 Amp INJ Fuel Injectors 1, 4, 6, 7
  5. 5 - 10 Amp INJ Fuel Injectors 2, 3, 5, 8
  6. 6 - 10 Amp IGN 1 A/C, Automatic Door Locks, Cruise Control, Instrument Panel Cluster, DERM, Cornering Lights, Chime Module, Twilight Sentinel/DRL Module, Backup Lights, Brake Transmission Shift Interlock
  7. 7 - 20 Amp FUEL PUMP Fuel Pump
  8. 8 - 10 Amp PCM (BAT) Powertrain Control Module
  9. 9 - 10 Amp BLWR FDBK Front Blower Motor Feedback
  10. 10 - Not Used
  11. 11 - 10 Amp A/C Comp A/C Compressor
  12. 12 - 10 Amp HTD W/S Heated Windshield
  13. 13 - 20 Amp STOP LP Stop Lights, Electronic Brake Control Module (EBCM)
  14. 14 - 20 Amp TURN/HAZ Hazard Lights, Turn Signal Light
  15. 15 - Not Used
  16. 16 - Not Used
  17. 17 - 10 Amp DRL Daytime Running Lights (Canadian)
  18. 18 - 10 Amp DRL Daytime Running Lights (Canadian)
  19. 19 - Not Used
  20. 20 - Not Used
  21. 21 - Not Used
  22. 22 - 10 Amp L HDLP LO (Export) Left Headlamp Low Beam
  23. 23 - 10 Amp R HDLP LO (Export) Right Headlamp Low Beam
  24. 24 - 20 Amp L HDLP HI (Export) Left Headlamp High Beam
  25. 25 - 10 Amp R HDLP HI (Export) Right Headlamp High Beam
  26. 26 - 10 Amp IGN 3 Heated Windshield, Heater - A/C Programmer, Electronic Level Control, Rear Defogger, Outside Rear View Mirror Defoggers, Cruise Control
  27. 27 - 10 Amp COOL FAN Cooling Fans
  28. 28 - 10 Amp TRANS EGR Solenoid, Power Steering Pressure Switch, Overspeed Alert Alarm (Export), Automatic Transaxle, Vapor Canister Purge Solenoid, VCC Brake Switch

Scheme 4

Scheme 4: TRUNK COMPARTMENT FUSE PANEL I.D. (1992 ELDORADO)
Scheme 4: TRUNK COMPARTMENT FUSE PANEL I.D. (1992 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp CRANK RAP/Illuminated Entry Module, Diagnostic Energy Reserve Module (DERM)
  2. 2 - 10 Amp IGN 1 Catalytic Converter Alarm Module (Export), Fuel Level Sensor, Electrochromic Mirror, Theft Deterrent Module, Keyless Entry Module, Turn Signal Lights, RAP/Illuminated Entry Module
  3. 3 - 30 Amp HDLP WASH (Export) Headlight Washer Module
  4. 4 - 10 Amp REAR BLWR Rear Blower Motor, Console Switch
  5. 5 - 10 Amp IPC (IGN) Instrument Panel Cluster
  6. 6 - 10 Amp CCR Computer Command Ride Module
  7. 7 - 10 Amp ABS Electronic Brake Control Module
  8. 8 - 30 Amp WIPER Wiper/Washer Switch
  9. 9 - 10 Amp RAD (IGN) Radio Chassis
  10. 10 - 30 Amp R DEFOG Rear Defogger
  11. 11 - 10 Amp HTD MPR Right/Left Power Mirror Defogger
  12. 12 - 10 Amp IPC (BAT) Instrument Panel Cluster
  13. 13 - 10 Amp THEFT Passkey Decoder Module, Theft Deterrent Relay/Module
  14. 14 - 10 Amp HVAC/DABIE Heater/A/C Programmer, RAP/Illuminated Entry Module
  15. 15 - 10 Amp REAR FOG Rear Foglight (Export)
  16. 16 - 10 Amp FOG LP Foglight (Export)
  17. 17 - 10 Amp ANT Power Antenna
  18. 18 - 20 Amp CIGAR Front/Rear Cigarette Lighters, Chime Module
  19. 19 - 10 Amp BODY 2 Power Mirror Switch, Retained Accessory Power (RAP), Trunk Light, Console Switch, Panel Lights, Courtesy Lights Keyless Entry Module
  20. 20 - 10 Amp BODY 1 Power Door Locks, Door Lock Cylinder Illumination, Glove Box/Footwell Lights, Twilight Sentinel/DRL Module, Headlight Switch
  21. 21 - 10 Amp READ LP Left/Right Vanity Mirrors, Garage Door Opener, Front/Rear Header Lights
  22. 22 - 10 Amp L PARK LP Radio Dimming, Headlight Switch, Instrument Panel Cluster, Left Taillight, Stoplight & Turn Light, Left Marker Light, Left Parking & Turn Light, All Interior Dimming
  23. 23 - 10 Amp R PARK LP Right Marker Light, License Lights, Right Parking & Turn Light, Engine Compartment Light, Right Taillight, Stoplight & Turn Light
  24. 24 - 10 Amp RAD (BAT) Radio
  25. 25 - 20 Amp TRUNK PLB Trunk Pull-Down
  26. 26 - 20 Amp ELC Electronic Level Control
  27. 27 - 10 Amp R HTD SEAT Passenger's Heated Seat
  28. 28 - 10 Amp L HTD SEAT Driver's Heated Seat

HIGH-CURRENT FUSE PANEL IDENTIFICATION (1992 ELDORADO)

The Maxi-Fuse high-current and Relay Panel is located next to the engine compartment fuse block.

WARNINGAlways disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician.

Scheme 5

Scheme 5
Scheme 5

L/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 50 Amp IGN 1 Retained Accessory Power (Radio/Wipers)
  2. 2 - 60 Amp BODY 1 Trunk Comp Fuses 16, 17, 18, 19, 20 & 21
  3. 3 - 30 Amp SEATS/HORN Circuit Breaker Power seat switches, Lumbar Control, Power Door Locks, Horns, Keyless Entry Module, Fuel Door/Trunk Release Switch
  4. 4 - 30 Amp ELECTRONICS Engine Compartment Fuse 8, Trunk Compartment Fuses 12, 13 & 14
  5. 5 - 60 Amp Body 2 Trunk Compartment Fuses 24, 25, 26, 27 & 28, Rear Defogger, Mirror Defogger
  6. 6 - 60 Amp IGN 3 Retained Accessory Power (Sunroof/Power Windows)

R/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 40 Amp EXT. LAMPS Engine Compartment Fuses 13 & 14, Parking Lights
  2. 2 - 30 Amp RADIO Trunk Compartment Fuse 24, Delco-Bose Speakers
  3. 3 - 30 Amp HEADLAMPS Circuit Breaker Flash-To-Pass, Headlights, Daytime Running Lights (DRL)
  4. 4 - 40 Amp HVAC BLOWER HVAC Power Module, Engine Compartment Fuse 11
  5. 5 - 50 Amp ABS Hydraulic Brake Modulator
  6. 6 - 50 Amp COOLING FANS Cooling Fans

UNDERHOOD FUSE PANEL IDENTIFICATION (1993 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp COIL Distributor (4.9L), Ignition Control Module (4.6L)
  2. 2 - 20 Amp SIR Diagnostic Energy Reserve Module (DERM), SIR (Air Bag), Arming Sensor
  3. 3 - 10 Amp PCM (IGN) Passkey Decoder Module, Powertrain Control Module
  4. 4 - 10 Amp INJ Fuel Injectors 1, 4, 6 & 7
  5. 5 - 10 Amp INJ Fuel Injectors 2, 3, 5 & 8
  6. 6 - 10 Amp IGN A/C Compressor, Chime Module, Electrochromic Mirror, Instrument Panel Cluster, DERM, SIR (Air Bag), Keyless Entry Module, Cornering Lights, Twilight Sentinel/DRL Module, Back-Up Lights, Brake Transmission Shift Interlock
  7. 7 - 20 Amp FUEL Fuel Pump, Powertrain Control Module
  8. 8 - 10 Amp PCM (BAT) Powertrain Control Module
  9. 9 - Not Used
  10. 10 - Not Used
  11. 11 - 10 Amp A/C A/C Compressor
  12. 12 - 10 Amp SENSE Heated Windshield
  13. 13 - 20 Amp STOP Stop Lights
  14. 14 - 20 Amp TURN/HAZ Hazard/Turn Signal Lights
  15. 15 - 10 Amp DRL DRL Module (Canada)
  16. 16 - 10 Amp DRL DRL Module (Canada)
  17. 17 - Not Used
  18. 18 - 10 Amp SUSPENSION Road Sensing Suspension (Northstar), Speed Sensitive Suspension (4.9L)
  19. 19 - 20 Amp RTD (BAT) Road Sensing Suspension
  20. 20 - Not Used
  21. 21 - Not Used
  22. 22 - 10 Amp L HDLP LO Left Headlight Low Beam (Export)
  23. 23 - 10 Amp R HDLP LO Right Headlight Low Beam (Export)
  24. 24 - 10 Amp L HDLP HI Left Headlight High Beam (Export)
  25. 25 - 10 Amp R HDLP HI Right Headlight High Beam (Export)
  26. 26 - 10 Amp IGN 3 Heated Windshield, Heater/A/C Programmer, Electronic Level Control, Defogger Relay "D", Cruise Control, Powertrain Control Module
  27. 27 - 10 Amp COOL FAN Cooling Fans, Powertrain Control Module (4.6L), Front/Rear Heated O2 Sensor (4.6L)
  28. 28 - 10 Amp TRANS/ECS EGR Solenoid, Auto. Transaxle, Powertrain Control Module, Evap Emission Control Solenoid, Overspeed Alert Module Export), Power Steering Pressure Switch

TRUNK COMPARTMENT FUSE PANEL I.D. (1993 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp CRANK RAP/Illuminated Entry Module, Diagnostic Energy Reserve Module (DERM), Starter
  2. 2 - 10 Amp IGN 1 Catalytic Converter Alarm Module (Export), Fuel Level Sensor, Electrochromic Mirror, Theft Deterrent Module, Keyless Entry Module, Turn Signal Lights, RAP/Illuminated Entry Module
  3. 3 - Not Used
  4. 4 - 30 Amp HDLP WASH (Export) Headlight Washer Module
  5. 5 - 10 Amp IPC (IGN) Instrument Panel Cluster
  6. 6 - 10 Amp CNSL SW Rear Blower, Console Switch
  7. 7 - 10 Amp ABS Electronic Brake Control Module (4.9L), Electronic Brake & Traction Control Module (Northstar)
  8. 8 - 30 Amp WIPER Wiper/Washer Switch
  9. 9 - 10 Amp RAD (IGN) Remote Radio Receiver
  10. 10 - 30 Amp R DEFOG Rear Defogger
  11. 11 - 10 Amp HTD MIRR Right/Left Power Mirror Defogger
  12. 12 - 10 Amp IPC (BAT) Instrument Panel Cluster
  13. 13 - 10 Amp THEFT Passkey Decoder Module, Theft Deterrent Relay/Module
  14. 14 - 10 Amp HVAC/DABIE Heater/A/C Programmer, RAP/Illuminated Entry Module
  15. 15 - 10 Amp REAR FOG Rear Foglights (Export)
  16. 16 - 10 Amp FOG LP Foglights (Export)
  17. 17 - 10 Amp CNSL FAN Rear Blower Motor
  18. 18 - 20 Amp CIGAR Front/Rear Cigarette Lighters, Chime Module
  19. 19 - 10 Amp BODY 2 Power Mirror Switch, Retained Accessory Power (RAP), Trunk Light, Console Switch, Panel Lights Inhibit (Export), Courtesy Lights, Keyless Entry Module
  20. 20 - 10 Amp BODY 1 Power Door Locks, Door Lock Cylinder Illumination, Glove Box/Footwell Lights, Twilight Sentinel/DRL Module, Headlight Switch
  21. 21 - 10 Amp READ LP Left/Right Vanity Mirrors, Garage Door Opener, Front/Rear Header Lights
  22. 22 - 10 Amp L PARK LP Radio Dimming, Headlight Switch, Instrument Panel Cluster, Left Taillight, Stoplight & Turn Light, Left Marker Light, Left Parking & Turn Light
  23. 23 - 10 Amp R PARK LP Right Marker Light, License Lights, Right Parking & Turn Light, Engine Compartment Light, Right Taillight, Stoplight & Turn Light
  24. 24 - 10 Amp RAD (BAT) Remote Radio Receiver, Radio Control Head
  25. 25 - 20 Amp ANT/TRUNK Trunk Pull-Down, Power Antenna
  26. 26 - 20 Amp ELC Electronic Level Control
  27. 27 - 10 Amp R HTD SEAT Passenger's Heated Seat
  28. 28 - 10 Amp L HTD SEAT Driver's Heated Seat

HIGH-CURRENT FUSE PANEL IDENTIFICATION (1993 ELDORADO)

The Maxi-Fuse high-current and Relay Panel is located next to the engine compartment fuse block.

WARNINGAlways disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician.

L/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 50 Amp Retained Accessory Power (Radio/Wipers), Starter, Trunk Comp Fuse 2, Engine Comp Fuses 1, 2, 3, 4, 5, 6 & 7
  2. 2 - 60 Amp Trunk Comp Fuses 16, 17, 18, 19, 20 & 21, Road Sensing Suspension, Rear Fog Light (Export)
  3. 3 - 30 Amp Circuit Breaker Power seat Switches, Lumbar Control, Power Door Locks, Horns, Keyless Entry Module, Fuel Door/Trunk Release Switch
  4. 4 - 30 Amp Powertrain Control Module, Electronic Climate Control, RAP/Illuminated Entry Module, Instrument panel Cluster, Pass-Key Decoder Module, Theft Deterrent
  5. 5 - 60 Amp L & R Heated Seats, Electronic Level Control, Deck Lid Pull Down, Power Antenna, Rear Defogger, Heated Mirrors
  6. 6 - 60 Amp Retained Accessory Power (Sunroof/Power Windows), Engine Comp Fuses 18, 26, 27, & 28, Trunk Comp Fuses 4, 5, 6, & 7

R/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 40 Amp Engine Comp Fuses 13 & 14, Parking Lights
  2. 2 - 30 Amp Delco-Bose Speakers, Radio Control Head, Remote Radio Receiver
  3. 3 - 30 Amp Circuit Breaker Flash-To-Pass, Daytime Running Lights, Headlights
  4. 4 - 40 Amp HVAC Power Module, A/C Compressor
  5. 5 - 50 Amp Anti-Lock Brake Pressure Valve
  6. 6 - 50 Amp Cooling Fans

UNDERHOOD FUSE PANEL IDENTIFICATION (1994-98 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp DISTR Ignition Control Module
  2. 2 - 20 Amp SIR DERM, Dual Pole Arming Sensor
  3. 3 - 10 Amp PCM (IGN) Powertrain Control Module, Pass-Key Decoder Module
  4. 4 - 10 Amp INJ Fuel Injectors 1, 4, 6 & 7
  5. 5 - 10 Amp INJ Fuel Injectors 2, 3, 5 & 8
  6. 6 - 10 Amp IGN 1 A/C Refrigerant Press. Switch, Transaxle Range Switch, Stop/BTSI/Cruise Brake Switch, Instrument Panel Cluster, Keyless Entry Module, DERM, Cornering Lights, Turn/Hazard Switch Assy., Chime Module, Headlight Switch, Twilight Sentinel/DRL Module
  7. 7 - 20 Amp FUEL PUMP Fuel Pump, Oil Press. Switch, Powertrain Control Module
  8. 8 - 10 Amp PCM (BAT) Powertrain Control Module
  9. 9 - 20 Amp RTD (BAT) Road Sensing Suspension (RSS) Module
  10. 10 - Not Used
  11. 11 - 10 Amp A/C COMP A/C Compressor Clutch
  12. 12 - 30 Amp HDLPS Headlight Dimmer Switch, Headlight Relay "D" (Engine Comp. Micro Relay Center) DRL Headlight Relay "E" (With Daytime Running Lights), Power: Fuse 15
  13. 13 - 20 Amp STOP LP Stop/BTSI/Cruise Switch, Stoplight Switch Capacitor
  14. 14 - 20 Amp TURN/HAZ Hazard Flasher, Turn Flasher Relay, Turn Flasher Module
  15. 15 - 10 Amp DRL DRL (Canada) Daytime Running Lights
  16. 16 - 10 Amp DRL Left & Right Lo Beam Headlamp
  17. 17 - 10 Amp HTD W/S Heated Windshield Control Module
  18. 18 - 10 Amp LR STRUT Left Rear Strut
  19. 19 - 10 Amp RR STRUT Right Rear Strut
  20. 20 - 10 Amp LF STRUT Left Front Strut
  21. 21 - 10 Amp RF STRUT Right Front Strut
  22. 22 - 10 Amp L HDLP LO Left Lo Beam Headlamp
  23. 23 - 10 Amp R HDLP LO Right Lo Beam Headlamp
  24. 24 - 10 Amp L HDLP HI Left Hi Beam Headlamp
  25. 25 - 10 Amp R HDLP HI Right Hi Beam Headlamp
  26. 26 - 10 Amp IGN 3 Rear Defogger Relay, Electronic Level Control (ELC), Heated Windshield, Heater and A/C Programmer, Cruise Control
  27. 27 - 10 Amp COOL FAN Extended Travel Brake Switch, Powertrain Control Module PCM), Cooling Fan Relays 1, 2, and 3, Front & Rear Heated O2 Sensors
  28. 28 - 10 Amp TRANS/ECS Overspeed Alert Module (Export), Power Steering Pressure Switch, Exhaust Gas Recirculation (EGR) Valve, Transaxle Shift Solenoids A & B, Evaporative Emission Control Solenoid, Powertrain Control Module (PCM), Torque Converter Clutch Solenoid, TCC Brake Switch

TRUNK COMPARTMENT FUSE PANEL I.D. (1994-98 ELDORADO)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp CRANK RAP/Illuminated Entry Module, Diagnostic Energy Reserve Module (DERM), Transaxle Range Switch (NSSS)
  2. 2 - 10 Amp IGN 1 Fuel Level Sensor, Electrochromic Mirror, Theft Deterrent Module, Keyless Entry Module, Turn Signals, RAP/Illuminated Entry Module, Turn Flasher Relay "F", Catalytic Converter Alarm Module (Export)
  3. 3 - 30 Amp HDLP WASH (Export) Headlight Washer Module
  4. 4 - 10 Amp SUSP Road Sensing Suspension Module
  5. 5 - 10 Amp IPC (IGN) Instrument Panel Cluster
  6. 6 - 10 Amp CNSL SW Rear Blower Relay "E", Console Switch
  7. 7 - 10 Amp ABS Electronic Brake & Traction Control Module (EBTCM)
  8. 8 - 30 Amp WIPER Wiper/Washer Switch
  9. 9 - 10 Amp RAD (IGN) Remote Radio Receiver
  10. 10 - 30 Amp R DEFOG Rear Defogger
  11. 11 - 10 Amp HTD MIRR Right/Left Power Mirror Defogger
  12. 12 - 10 Amp IPC (BAT) Instrument Panel Cluster
  13. 13 - 10 Amp THEFT Passkey Decoder Module, Theft Deterrent Relay "D", Theft Deterrent Module
  14. 14 - 10 Amp HVAC/DABIE Heater/A/C Programmer, RAP/Illuminated Entry Module
  15. 15 - 10 Amp REAR FOG Rear Foglight Relay "A" (Export)
  16. 16 - 10 Amp FOG LP Foglight Relays "A" & "F" (Export)
  17. 17 - 10 Amp CNSL FAN Rear Blower Motor, Rear Blower Relay
  18. 18 - 20 Amp CIGAR Front/Rear Cigarette Lighters, Chime Module
  19. 19 - 10 Amp BODY 2 Power Mirror Switch, Retained Accessory Power (RAP) Relay, Lock-Out Inhibit Relay "B", Panel Lights Inhibit Relay "F" Export), Courtesy Lights Relay "C", RAP Relay "E", Keyless Entry Module, Trunk Light, Seat Belt Retractor Solenoids
  20. 20 - 10 Amp BODY 1 Front Door Lock Switches, Glove Box/Footwell Lights, Headlight Switch
  21. 21 - 10 Amp READ LP Left/Right Vanity Mirrors, Garage Door Opener, Front/Rear Header Lights
  22. 22 - 10 Amp L PARK LP Headlight Switch, Instrument Panel Cluster, Radio Control Head, Left Taillight, Stoplight & Turn Light, Left Marker Light, Left Parking & Turn Light
  23. 23 - 10 Amp R PARK LP Right Marker Light, License Lights, Right Parking & Turn Light, Engine Compartment Light, Right Taillight, Stoplight & Turn Light
  24. 24 - 10 Amp RAD (BAT) Radio
  25. 25 - 20 Amp ANT/TRUNK Trunk Pull-Down, Power Antenna
  26. 26 - 20 Amp ELC Electronic Level Control
  27. 27 - 10 Amp R HTD SEAT Passenger's Heated Seat
  28. 28 - 10 Amp L HTD SEAT Driver's Heated Seat

HIGH-CURRENT FUSE PANEL IDENTIFICATION (1994-98 ELDORADO)

The Maxi-Fuse high-current and Relay Panel is located next to the engine compartment fuse block.

WARNINGAlways disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician.

L/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 50 Amp STRG 1-2 Retained Accessory Power (Radio/Wipers), Starter, Trunk Comp Fuses 8 & 9
  2. 2 - 60 Amp BODY Engine Comp Fuse 9, Road Sensing Suspension, Fog Lights, Trunk Comp Fuses 16, 17, 18, 19, 20 & 21
  3. 3 - 30 Amp SEAT Circuit Breaker Power seat switches, Lumbar Relays, Power Door Locks, Keyless Entry Module, Horns, Fuel Door/Trunk Release Switch
  4. 4 - 30 Amp IPC Powertrain Control Module, Electronic Climate Control, RAP/Illuminated Entry Module, Instrument panel Cluster, Pass-Key Decoder Module, Theft Deterrent
  5. 5 - 60 Amp HVAC L & R Heated Seats, Electronic Level Control, Deck Lid Pull Down, Power Antenna, Rear Defogger, Heated Mirrors
  6. 6 - 60 Amp STRG 3 Retained Accessory Power (Sunroof/Power Windows), Engine Comp Fuses 26, 27, & 28, Trunk Comp Fuses 3, 4, 5, 6, & 7

R/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 30 Amp DAB Circuit Breaker Retained Accessory Power (Sunroof/Power Windows)
  2. 2 - 30 Amp RADIO Delco-Bose Speakers, Radio Control Head, Remote Radio Receiver
  3. 3 - 50 Amp COOL Cooling Fans
  4. 4 - 40 Amp HVAC BLOWER (BLOWER) HVAC Power Motor, A/C Compressor
  5. 5 - 50 Amp ABS (BRAKES) Brake Pressure Modulator Valve
  6. 6 - 50 Amp LAMPS Turn Flasher Module, Hazard Flasher, Stop/BTSI/Cruise Brake Switch, Parking Lights, Daytime Running Lights (Canada), Engine Comp Fuses 12, 13 & 14, Trunk Comp Fuses 22 & 23

Scheme 6

Scheme 6: FUSE PANEL IDENTIFICATION (1986-92)
Scheme 6: FUSE PANEL IDENTIFICATION (1986-92)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Electrical Exhaust
  2. 2 - 20 Amp Body
  3. 3 - 10 Amp Antenna
  4. 4 - 20 Amp Cigarette Lighter
  5. 5 - 15 Amp CPS
  6. 6 - 20 Amp Electronic Level Control Compressor
  7. 7 - 5 Amp Blower Motor
  8. 8 - 3 Amp Cruise Control
  9. 9 - 7.5 Amp HVAC
  10. 10 - 3 Amp Body Control Module
  11. 11 - 10 Amp Radio
  12. 12 - 25 Amp Windshield/Washer Wiper
  13. 13 - 15 Amp Deck Lid
  14. 14 - 10 Amp Body Control Module
  15. 15 - 15 Amp Taillights
  16. 16 - 20 Amp Stoplight/Hazard Warning Light
  17. 17 - 10 Amp Radio Power
  18. 18 - 10 Amp Ignition #1-ISO
  19. 19 - 15 Amp Air Bags
  20. 20 - 30 Amp Defogger
  21. 21 - 10 Amp (Circuit Breaker) Low-Beam Lights
  22. 22 - 20 Amp (Circuit Breaker) High-Beam Lights
  23. 23 - 30 Amp (Circuit Breaker) Seats
  24. 24 - 30 Amp (Circuit Breaker) Retained Accessory Power (RAP) & Horn
  25. 25 - Blank

Scheme 7

Scheme 7: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION (1993 SEVILLE)
Scheme 7: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION (1993 SEVILLE)

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp Distributor (4.9L), Ignition Control Module (4.6L)
  2. 2 - 20 Amp DERM Module, Arming Sensor, Supplemental Restraint System
  3. 3 - 10 Amp Powertrain Control Module, Passkey Decoder Module
  4. 4 - 10 Amp Fuel Injectors 1, 4, 6 & 7
  5. 5 - 10 Amp Fuel Injectors 2, 3, 5 & 8
  6. 6 - 10 Amp A/C Compressor, Electric Mirror, Instrument Panel Cluster, DERM Module, SIR System, Keyless Entry Module, Cornering/Back-Up Lights, Chime Module, DRL Module, Twilight Sentinel, Brake Transmission Shift Interlock
  7. 7 - 20 Amp Fuel Pump, Powertrain Control Module
  8. 8 - 10 Amp Powertrain Control Module
  9. 9 - Not Used
  10. 10 - Not Used
  11. 11 - 10 Amp A/C Compressor
  12. 12 - 10 Amp Heated Windshield
  13. 13 - 20 Amp Stop Lights
  14. 14 - 20 Amp Turn/Hazard Lights
  15. 15 - 10 Amp DRL Module (Canada)
  16. 16 - 10 Amp DRL Module (Canada)
  17. 17 - Not Used
  18. 18 - 10 Amp Road Sensing Suspension (4.6L), Speed Sensitive Suspension 4.9L)
  19. 19 - 20 Amp Road Sensing Suspension
  20. 20 - Not Used
  21. 21 - Not Used
  22. 22 - 10 Amp Left Low-Beam Lights (Export)
  23. 23 - 10 Amp Right Low-Beam Lights (Export)
  24. 24 - 10 Amp Left High-Beam Light (Export)
  25. 25 - 10 Amp Right High-Beam Light (Export)
  26. 26 - 10 Amp Heated Windshield, Heater/A/C Programmer, Electronic Level Control, Defogger Relay D, Cruise Control, Powertrain Control Module
  27. 27 - 10 Amp Cooling Fans, Powertrain Control Module (4.6L), Front/Rear Heated Oxygen Sensor (4.6L)
  28. 28 - 10 Amp EGR Solenoid, Powertrain Control Module, Automatic Transaxle, EVAP Control Solenoid, Overspeed Alert Module (Export), Power Steering Pressure Switch

HIGH-CURRENT FUSE PANEL IDENTIFICATION (1994-96 SEVILLE)

The Maxi-Fuse high-current and Relay Panel is located next to the engine compartment fuse block.

WARNINGAlways disconnect battery ground cable before servicing high-current fuses. It is recommended that high-current fuses be replaced by a qualified technician.

L/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 50 Amp STRG 1-2 Retained Accessory Power (Radio/Wipers), Starter, Trunk Comp Fuses 8 & 9
  2. 2 - 60 Amp BODY Engine Comp Fuse 9, Road Sensing Suspension, Fog Lights, Trunk Comp Fuses 16, 17, 18, 19, 20 & 21
  3. 3 - 30 Amp Circuit Breaker SEAT Power seat switches, Lumbar Relays, Power Door Locks, Keyless Entry Module, Horns, Fuel Door/Trunk Release Switch
  4. 4 - 30 Amp IPC Powertrain Control Module, Electronic Climate Control, RAP/Illuminated Entry Module, Instrument panel Cluster, Pass-Key Decoder Module, Theft Deterrent
  5. 5 - 60 Amp HVAC L & R Heated Seats, Electronic Level Control, Deck Lid Pull Down, Power Antenna, Rear Defogger, Heated Mirrors
  6. 6 - 60 Amp STRG 3 Retained Accessory Power (Sunroof/Power Windows), Engine Comp Fuses 26, 27, & 28, Trunk Comp Fuses 3, 4, 5, 6, & 7

R/H Maxi-Fuse & Circuit Breaker Identification

  1. 1 - 30 Amp DAB Circuit Breaker Retained Accessory Power (Sunroof/Power Windows)
  2. 2 - 30 Amp RADIO Delco-Bose Speakers, Radio Control Head, Remote Radio Receiver
  3. 3 - 50 Amp COOL Cooling Fans
  4. 4 - 40 Amp HVAC BLOWER (MOTOR) HVAC Power Motor, A/C Compressor
  5. 5 - 50 Amp ABS (BRAKES) Brake Pressure Modulator Valve
  6. 6 - 50 Amp LAMPS Turn Flasher Module, Hazard Flasher, Stop/BTSI/Cruise Brake Switch, Parking Lights, Daytime Running Lights (Canada), Engine Comp Fuses 12, 13 & 14, Trunk Comp Fuses 22 & 23

Scheme 8

Scheme 8: TRUNK COMPARTMENT FUSE PANEL ID (1993-98 SEVILLE)
Scheme 8: TRUNK COMPARTMENT FUSE PANEL ID (1993-98 SEVILLE)

Fuse & Circuit Breaker Identification (1993-98 Seville)

  1. 1 - 10 Amp Retained Accessory Power, Illuminated Entry, DERM Module, Starter
  2. 2 - 10 Amp Catalytic Converter Alarm (Export), Fuel level Sensor, Turn Signals, Electric Mirror, Keyless Entry, Retained Accessory Power, Illuminated Entry, Theft Deterrent Module
  3. 3 - Not Used
  4. 4 - 30 Amp Headlight Washer (Export)
  5. 5 - 10 Amp Instrument Panel Cluster
  6. 6 - 10 Amp Rear Blower Motor, Console Switch
  7. 7 - 10 Amp Electric Brake Control (4.9L), Electric Brake/Traction Control (4.6L)
  8. 8 - 30 Amp Wiper/Washer Switch
  9. 9 - 10 Amp Remote Radio Receiver
  10. 10 - 30 Amp Rear Defogger
  11. 11 - 10 Amp Heated Mirrors
  12. 12 - 10 Amp Instrument Panel Cluster
  13. 13 - 10 Amp Passkey Decoder Module, Theft Deterrent Relay/Module
  14. 14 - 10 Amp Heater/A/C Programmer, Retained Accessory Power, Illuminated Accessory Power
  15. 15 - 10 Amp Rear Fog Lights (Export)
  16. 16 - 10 Amp Fog Lights (4.6L)
  17. 17 - 10 Amp Rear Blower Motor
  18. 18 - 20 Amp Cigarette Lighters, Chime Module
  19. 19 - 10 Amp Power Mirror Switch, Retained Accessory Power, Trunk/Courtesy Lights, Console Switch, Panel Light Inhibit (Export), Keyless Entry Module
  20. 20 - 10 Amp Power Door Locks, Door Lock Cylinder Light, Glove Box Light, Footwell Lights, Twilight Sentinel, DRL Module, Headlight Switch
  21. 21 - 10 Amp Vanity Mirrors, Garage Door Openers, Front/Rear Header Lights
  22. 22 - 10 Amp Radio Dimming, Headlight Switch, Instrument Panel Cluster, Left Park/Turn/Marker/Tail/Stoplights
  23. 23 - 10 Amp Right Park/Turn/Marker/Tail/Stoplights, License Lights, Engine Compartment Light
  24. 24 - 10 Amp Remote Radio Receiver, Radio Control Head
  25. 25 - 20 Amp Trunk Pull-Down, Power Antenna
  26. 26 - 20 Amp Electronic Level Control
  27. 27 - 10 Amp Passenger Heated Seat
  28. 28 - 10 Amp Driver Heated Seat

Fuse & Circuit Breaker Identification (1994-98)

  1. 1 - 10 Amp CRANK Retained Accessory Power, Illuminated Entry, DERM Module, Transaxle Range Switch (NSSS)
  2. 2 - 10 Amp IGN 1 Catalytic Converter Alarm (Export), Fuel level Sensor, Turn Signals, Electric Mirror, ,Keyless Entry, Retained Accessory Power, Illuminated Entry, Theft Deterrent Module, Turn Flasher Relay "F"
  3. 3 - 30 Amp HDLP WASH Headlight Washer Module (Export Only)
  4. 4 - Not Used
  5. 5 - 10 Amp IPC (IGN) Instrument Panel Cluster
  6. 6 - 10 Amp RTD Road Sensing Suspension, Speed Sensitive Suspension, RSS Damper Relay "F"
  7. 7 - 10 Amp ABS Electric Brake/Traction Control Module
  8. 8 - 30 Amp WIPER Wiper/Washer Switch
  9. 9 - 10 Amp RAD (IGN) Remote Radio Receiver
  10. 10 - 30 Amp R DEFOG Rear Defogger
  11. 11 - 10 Amp HTD MIRR Heated Mirrors
  12. 12 - 10 Amp IPC (BAT) Instrument Panel Cluster
  13. 13 - 10 Amp THEFT Passkey Decoder Module, Theft Deterrent Relay "D", Theft Deterrent Module
  14. 14 - 10 Amp HVAC/DABIE Heater/A/C Programmer, Retained Accessory Power, Illuminated Accessory Power
  15. 15 - 10 Amp RADIO (AMP) Active Audio Amplifier
  16. 16 - 10 Amp TRAILER Trailer L & R Turn Relay
  17. 17 - 10 Amp ANT Rear Blower Relay "E", Power Antenna Relay
  18. 18 - 20 Amp CIGAR Cigarette Lighters, Chime Module
  19. 19 - 10 Amp BODY 2 Power Mirror Switch, Retained Accessory Power, Trunk/Courtesy Lights, Console Switch, Panel Light Inhibit (Export), Keyless Entry Module
  20. 20 - 10 Amp BODY 1 Power Door Locks, Door Lock Cylinder Light, Glove Box Light, Footwell Lights, Twilight Sentinel, DRL Module, Headlight Switch
  21. 21 - 10 Amp READ LP Vanity Mirrors, Garage Door Openers, Front/Rear Header Lights
  22. 22 - 10 Amp L PRK LP Radio Dimming, Headlight Switch, Instrument Panel Cluster, Left Park/Turn/Marker/Tail/Stoplights
  23. 23 - 10 Amp R PRK LP Right Park/Turn/Marker/Tail/Stoplights, License Lights, Engine Compartment Light
  24. 24 - 10 Amp RAD (BAT) Remote Radio Receiver, Radio Control Head
  25. 25 - 20 Amp TRUNK PLD Trunk Pull-Down, Power Antenna
  26. 26 - 20 Amp ELC Electronic Level Control
  27. 27 - 10 Amp R HTD SEAT Passenger Heated Seat
  28. 28 - 10 Amp L HTD SEAT Driver Heated Seat

FUSE PANEL IDENTIFICATION (1994-98 SEVILLE)

Fuse & Circuit Breaker Identification

  1. 1 - 20 Amp DISTR Ignition Control Module
  2. 2 - 20 Amp SIR DERM, Dual Pole Arming Sensor
  3. 3 - 10 Amp PCM (IGN) Powertrain Control Module, Pass-Key Decoder Module
  4. 4 - 10 Amp INJ Fuel Injectors 1, 4, 6 & 7
  5. 5 - 10 Amp INJ Fuel Injectors 2, 3, 5 & 8
  6. 6 - 10 Amp IGN 1 A/C Refrigerant Press. Sw., Transaxle Range Sw., Stop/BTSI/Cruise Brake Sw., Instrument Panel Cluster, Keyless Entry Module, DERM, Cornering Lights, Turn/Hazard Sw. Assy., Chime Module, Headlight Sw., Twilight Sentinel/DRL Module
  7. 7 - 20 Amp FUEL PUMP Fuel Pump, Oil Press. Sw., Powertrain Control Module
  8. 8 - 10 Amp PCM (BAT) Powertrain Control Module
  9. 9 - 20 Amp RTD (BAT) Road Sensing Suspension (RSS) Module
  10. 10 - Not Used
  11. 11 - 10 Amp A/C Comp A/C Compressor Clutch
  12. 12 - 30 Amp HDLPS Headlight Dimmer Sw., Headlight Relay "D" (Engine Comp. Micro Relay Center) DRL Headlight Relay "E" (With Daytime Running Lights), Power C13
  13. 13 - 20 Amp STOP LP Stop/BTSI/Cruise Sw., Stoplight Sw. Capacitor
  14. 14 - 20 Amp TURN/HAZ Hazard Flasher, Turn Flasher Relay, Turn Flasher Module
  15. 15 - 10 Amp DRL Daytime Running Lights (Canada)
  16. 16 - 10 Amp DRL DRL Module (Canada), Left & Right Lo Beam Headlamp
  17. 17 - 10 Amp HTD W/S Heated Windshield Control Module
  18. 18 - 10 Amp LR STRUT Left Rear Strut
  19. 19 - 10 Amp RR STRUT Right Rear Strut
  20. 20 - 10 Amp LF STRUT Left Front Strut
  21. 21 - 10 Amp RF STRUT Right Front Strut
  22. 22 - 10 Amp L HDLP LO Left Lo Beam Headlamp
  23. 23 - 10 Amp R HDLP LO Right Lo Beam Headlamp
  24. 24 - 10 Amp L HDLP HI Left Hi Beam Headlamp
  25. 25 - 10 Amp R HDLP HI Right Hi Beam Headlamp
  26. 26 - 10 Amp IGN 3 Rear Defogger Relay, Electronic Level Control (ELC), Heated Windshield, Heater and A/C Programmer, Cruise Control
  27. 27 - 10 Amp COOL FAN Cooling Fan, Extended Travel Brake Sw., Powertrain Control Module (PCM), Cooling Fan Relays 1, 2, and 3, Front & Rear Heated O2 Sens.
  28. 28 - 10 Amp TRANS Overspeed Alert Module (Export), Power Steering Pressure Sw., Exhaust Gas Recirculation (EGR) Valve, Transaxle Shift Solenoids A & B, Evaporative Emission Control Solenoid, Powertrain Control Module (PCM), Torque Converter Clutch Solenoid, TCC Brake Sw.
