Heated wiper deicer circuit for Cadillac Lyriq I (2022-2024)
Heated wiper deicer circuit
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BATT POSITIVE VOLT
BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DE-ICE RLY CTRL
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT HEATER, AIR CONDITIONING USER INTERFACE CONTROL
HEATED WINDSHIELD RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LIGHTING CONTROL MODULE (LEFT SIDE OF DASH)
RED/VIO WIRE
RED/YEL WIRE
RIGHT END OF DASH)
VIO/BRN WIRE
WHT WIRE
WHT/GRN WIRE
WINDSHIELD HEATING GRID
