Cadillac Lyriq I (2022-2024) short range radar rear side sensor Wiring diagram
This page shows the only wiring diagram for the component.short range radar rear side sensor, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram short range radar rear side sensor (1 of 1)
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP RADIO AM ANTENNA SIGNAL FILTER MODULE
DRIVER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
EXTERIOR LIFTGATE RELEASE SWITCH
LEFT HANDLE REAR SIDE DOOR LIGHT CONDUCTOR LAMP
LEFT REAR CARGO CENTER COURTESY LAMP
LEFT REAR LICENSE PLATE LAMP
LEFT REAR SIDE DOOR COURTESY LAMP
LEFT REAR SIDE DOOR OUTSIDE HANDLE
LEFT REAR SIDE DOOR OUTSIDE HANDLE SWITCH
LEFT REAR SIDE DOOR POCKET ILLUMINATION LAMP
LEFT REAR SIDE DOOR WINDOW SWITCH
LEFT ROOF RAIL REAR SEAT POSITION READING, COURTESY LAMP
LEFT SHORT RANGE RADAR REAR SIDE SENSOR
LEFT SUNSHADE LEFT SUNSHADE MIRROR LAMP
LEFT TRIM PANEL REAR SIDE DOOR LIGHT CONDUCTOR LAMP
LIFTGATE COURTESY LAMP
NCA WIRE
REAR CLOSURE HANDS FREE MODULE
REMOTE FUNCTION ACTUATOR MODULE
RIGHT REAR CARGO CENTER COURTESY LAMP
RIGHT REAR LICENSE PLATE LAMP
RIGHT ROOF RAIL REAR SEAT POSITION READING, COURTESY LAMP
RIGHT SHORT RANGE RADAR REAR SIDE SENSOR
RIGHT SUNSHADE RIGHT SUNSHADE MIRROR LAMP
ROOF CONSOLE
RWD
SERIAL DATA GATEWAY MODULE
SHORT RANGE RADAR REAR SIDE SENSOR
W/ LANE ACTIVE SAFETY
W/O LANE ACTIVE SAFETY
WINDSHIELD OUTSIDE MOISTURE/ AMBIENT LIGHT, HUMIDITY SENSOR
Go to component -> Ground distribution circuit (7 of 8) -> SHORT RANGE RADAR REAR SIDE SENSOR
