Cadillac Lyriq I (2022-2024) seat memory switch sig 1 Wiring diagram
This page shows the only wiring diagram for the component.seat memory switch sig 1, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat memory switch sig 1 (1 of 1)
AUTOSAR CAN BUS (+) 4 SERIAL DATA
BATT POSITIVE VOLT
BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT ADJUSTER ACTUATOR
DRIVER FRONT SEAT RECLINER ACTUATOR
DRIVER FRONT SEAT TILT ADJUSTER ACTUATOR
DRIVER FRONT SEAT VERTICAL ADJUSTER ACTUATOR
DRIVER SEAT ADJUSTER MEMORY MODULE (IN DRIVER SEAT CUSHION)
DRIVER SEAT ADJUSTER MEMORY MODULE LIN BUS 1
DRIVER SEAT ADJUSTER MEMORY MODULE LIN BUS 2
DRIVER SEAT FRT VERT MTR DOWN CTRL
DRIVER SEAT FRT VERT MTR UP CTRL
DRIVER SEAT HORIZ MTR FWD CTRL
DRIVER SEAT HORIZ MTR RWD CTRL
DRIVER SEAT LR HAPTIC SEAT MOVEMENT MTR CTRL
DRIVER SEAT REAR VERT MTR UP CTRL
DRIVER SEAT RECLINE MTR FWD CTRL
DRIVER SEAT RECLINE MTR RWD CTRL
DRIVER SEAT RR HAPTIC SEAT MOVEMENT MTR CTRL
DRIVER SEAT VERT MTR DOWN CTRL
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/BRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
SEAT MEMORY SW SET SIG
SEAT MEMORY SWITCH SIG 1
SEATS SYSTEM
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> SEAT MEMORY SWITCH SIG 1
