Cadillac Lyriq I (2022-2024) rr trailer stop/ turn lamp control Wiring diagram
This page shows the only wiring diagram for the component.rr trailer stop/ turn lamp control, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr trailer stop/ turn lamp control (1 of 1)
AUTOSAR CAN BUS (-) 9 SER DATA
AUXILIARY PARK LAMP RELAY CONTROL
BATTERY POSITIVE VOLT
BATTERY POSITIVE VOLT LR TRAILER STOP/ TURN LAMP CONTROL
BLK WIRE
BLU/GRN WIRE
BLUNT CUT)
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/BRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
LIGHTING CONTROL MODULE (LEFT SIDE OF DASH)
NOT USED
PARKING LAMP RELAY
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RIGHT END OF DASH)
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RR TRAILER STOP/ TURN LAMP CONTROL
TRAILER BACKUP LAMP RELAY
TRAILER WIRING PROVISION
W/ TRAILER PROVISIONS
W/O TRAILER PROVISIONS
WHT/BRN WIRE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit -> RR TRAILER STOP/ TURN LAMP CONTROL
