Cadillac Lyriq I (2022-2024) right folding rear seat back actuator Wiring diagrams
This page contains all the electrical diagrams for the component. right folding rear seat back actuator, in which he is found in the car Cadillac Lyriq I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right folding rear seat back actuator (1 of 2)
BATTERY ENERGY CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
DRIVE MOTOR CONTROL MODULE
IMAGE PROCESSING MODULE
LEFT FOLDING REAR SEAT BACK ACTUATOR
LEFT FRONT SIDE MARKER LAMP
LEFT REAR BODY STRUCTURE STOP LAMP
LEFT REAR FASCIA LOWER SIGNAL LAMP
LEFT REAR FASCIA SIGNAL LAMP LEFT REAR FASCIA SIGNAL LAMP LED DRIVER MODULE
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE
NCA WIRE
PARKING ASSIST CONTROL MODULE
PASSENGER RESTRAINTS OCCUPANT CLASSIFICATION SYSTEM MODULE
QUARTER LOWER REAR TRIM PANEL ACCESSORY POWER RECEPTACLE
REAR CLOSURE AUXILIARY SIGNAL LAMP
REAR WINDOW DEFOGGER GRID
RESTRAINTS CONTROL MODULE
RIGHT FOLDING REAR SEAT BACK ACTUATOR
RIGHT FRONT SIDE MARKER LAMP
RIGHT REAR BODY STRUCTURE STOP LAMP
RIGHT REAR FASCIA LOWER SIGNAL LAMP
RIGHT REAR FASCIA SIGNAL LAMP RIGHT REAR FASCIA SIGNAL LAMP LED DRIVER MODULE
RIGHT SHORT RANGE RADAR REAR SIDE SENSOR
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE
TELEMATIC CONTROL MODULE
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 1
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 2
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 3
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 4
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 5
VEHICLE DYNAMICS SENSOR
W/ LANE ACTIVE SAFETY
W/O LANE ACTIVE SAFETY
Go to component -> Ground distribution circuit (4 of 8) -> RIGHT FOLDING REAR SEAT BACK ACTUATOR
Wiring diagram right folding rear seat back actuator (2 of 2)
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FOLDING REAR SEAT BACK ACTUATOR
LEFT FOLDING REAR SEAT BACK RELAY
LEFT REAR SEAT BACK FOLDING SWITCH
OUT OF PARK SIG
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FOLDING REAR SEAT BACK ACTUATOR
RIGHT FOLDING REAR SEAT BACK RELAY
RIGHT REAR SEAT BACK FOLDING SWITCH
TRANSMISSION PARK POSITION RELAY
VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Rear folding seat circuit -> RIGHT FOLDING REAR SEAT BACK ACTUATOR
