Cadillac Lyriq I (2022-2024) pass seat horiz mtr rwd ctrl Wiring diagram
This page shows the only wiring diagram for the component.pass seat horiz mtr rwd ctrl, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat horiz mtr rwd ctrl (1 of 1)
AUTOSAR CAN BUS (+) 4 SERIAL DATA
BATT POSITIVE VOLT
BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
PASS SEAT ADJUSTER MEMORY MODULE LIN BUS 2 AUTOSAR CAN BUS (-) 4 SERIAL DATA
PASS SEAT FRT VERT MTR DOWN CTRL
PASS SEAT FRT VERT MTR UP CTRL
PASS SEAT HORIZ MTR FWD CTRL
PASS SEAT HORIZ MTR RWD CTRL
PASS SEAT REAR VERT MTR DOWN CTRL
PASS SEAT REAR VERT MTR UP CTRL
PASS SEAT RECLINE MTR FWD CTRL
PASS SEAT RECLINE MTR RWD CTRL
PASSENGER FRONT SEAT ADJUSTER ACTUATOR
PASSENGER FRONT SEAT RECLINE ACTUATOR
PASSENGER FRONT SEAT TILT ADJUSTER ACTUATOR
PASSENGER FRONT SEAT VERTICAL ADJUSTER ACTUATOR
PASSENGER SEAT ADJUSTER MEMORY MODULE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
SEAT MEMORY MODULE CONFIGURATION 2
WHT WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Passenger"s memory seat circuit (1 of 2) -> PASS SEAT HORIZ MTR RWD CTRL
