Cadillac Lyriq I (2022-2024) pass seat heating temperature sens sig Wiring diagram
This page shows the only wiring diagram for the component.pass seat heating temperature sens sig, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat heating temperature sens sig (1 of 1)
BATT POSITIVE VOLT
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BODY CTRL MODULE LIN BUS 11
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT BACK HEATER
DRIVER FRONT SEAT CUSHION HEATER
DRV HEATED SEAT THERMISTOR LO REF
DRV SEAT BACK HEATING ELEMENT CTRL
DRV SEAT BLOWER MTR CTRL 1
DRV SEAT HEATING ELEMENT CTRL
DRV SEAT HEATING ELEMENT LO REF
DRV SEAT HEATING TEMPERATURE SENS SIG
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT SEAT HEATER VENT CONTROL MODULE (IN PASSENGER SEAT CUSHION)
GRN/VIO WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
NCA WIRE
PASS HEATED SEAT THERMISTOR LO REF
PASS SEAT BACK HEATING ELEMENT CTRL
PASS SEAT BLOWER MTR CTRL 1
PASS SEAT HEATING ELEMENT CTRL
PASS SEAT HEATING ELEMENT LO REF
PASS SEAT HEATING TEMPERATURE SENS SIG
PASSENGER HEATED BACK THERMISTOR LO REF
RED/GRN WIRE
RED/GRY WIRE
VIO/WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Front heated seats circuit (1 of 3) -> PASS SEAT HEATING TEMPERATURE SENS SIG
