Cadillac Lyriq I (2022-2024) on/off switch Wiring diagram
This page shows the only wiring diagram for the component.on/off switch, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/off switch (1 of 1)
A/C IND
A/C SWITCH
AIR CONDITIONING EVAPORATOR AIR TEMPERATURE SENSOR
AUTO IND
AUTO SWITCH
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFROST, LOWER AIR OUTLET IND
GRN/BRN WIRE
GRN/GRY WIRE
GRY WIRE
GRY/GRN WIRE
HEAT IND
HEAT SWITCH
HYBRID/ELECTRIC VEHICLE PROPULSION SYSTEM COOLANT CONTROL VALVE 2
HYBRID/ELECTRIC VEHICLE PROPULSION SYSTEM MAIN COOLANT CONTROL VALVE
LEFT TEMPERATURE SWITCH
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
MAX WINDSHIELD DEFROST IND
MAX WINDSHIELD DEFROST SWITCH
ON/OFF IND
ON/OFF SWITCH
REAR HEATED MIRROR IND
REAR HEATED MIRROR SWITCH
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT DUCT AIR TEMPERATURE SENSOR
RIGHT TEMPERATURE SWITCH
RWD
SUNLOAD, AMBIENT LIGHT, CHARGE INDICATOR SENSOR
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
VENTILATING FAN SWITCH
WHT/YEL WIRE
Go to component -> Automatic a/c circuit (3 of 6) -> ON/OFF SWITCH
