Cadillac Lyriq I (2022-2024) left rear side door outside handle lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear side door outside handle lamp, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side door outside handle lamp (1 of 1)
BLK WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN/GRY WIRE
BRN/WHT WIRE
DRIVER OUTSIDE REAR VIEW MIRROR EXTERIOR FLOOD LAMP
DRIVER OUTSIDE REAR VIEW MIRROR TURN SIGNAL LAMP
DRIVER OUTSIDE REAR- VIEW MIRROR
GRN/BLU WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/GRN WIRE
LEFT FRONT SIDE DOOR OUTSIDE HANDLE
LEFT FRONT SIDE DOOR OUTSIDE HANDLE LAMP
LEFT REAR SIDE DOOR OUTSIDE HANDLE
LEFT REAR SIDE DOOR OUTSIDE HANDLE LAMP
NCA WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT FRONT SIDE DOOR OUTSIDE HANDLE
RIGHT FRONT SIDE DOOR OUTSIDE HANDLE LAMP
RIGHT REAR SIDE DOOR OUTSIDE HANDLE
RIGHT REAR SIDE DOOR OUTSIDE HANDLE LAMP
RWD
VIO/BLK WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (2 of 6) -> LEFT REAR SIDE DOOR OUTSIDE HANDLE LAMP
