Cadillac Lyriq I (2022-2024) left quarter panel extension air bag side impact rear sensor Wiring diagram

BATTERY CUT-OFF MODULE LO CTRL BLK/ORG WIRE BLU/ORG WIRE BRN/ORG WIRE DRIV INBOARD SEAT SIDE AIR BAG HI CTRL DRIV INBOARD SEAT SIDE AIR BAG LO CTRL DRIV SEAT BACK AIR BAG HI CTRL DRIV SEAT BACK AIR BAG LO CTRL DRIV SEAT BELT SWITCH LO REF DRIVER FRONT SEAT OUTBOARD SEAT BACK AIR BAG DRIVER INSTRUMENT PANEL LOWER AIR BAG DRIVER SEAT BELT SENS SIG DRIVER SEAT BELT SWITCH DRIVER FRONT SEAT BELT BUCKLE GRN/ORG WIRE GRY/ORG WIRE LEFT FRONT DOOR AIR BAG SIDE IMPACT SENSOR LEFT FRONT, REAR ROW ROOF RAIL AIR BAG LEFT QUARTER PANEL EXTENSION AIR BAG SIDE IMPACT REAR SENSOR LEFT REAR SEAT BELT BUCKLE LEFT REAR SEAT BELT SWITCH LEFT REAR SIDE IMPACT SENS SIG LF ROOF RAIL AIR BAG HI CTRL LF ROOF RAIL AIR BAG LO CTRL LF SIDE IMPACT SENS LO REF LF SIDE IMPACT SENS SIG LR SEAT BELT PRETENSIONER CTRL LR SEAT BELT PRETENSIONER LO CTRL LR SEAT BELT SW SIG LR SIDE IMPACT SENS LO REF NCA WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/VIO WIRE ORG/WHT WIRE ORG/YEL WIRE PASS KNEE AIR BAG HI CTRL PASS KNEE AIR BAG LO CTRL PASS SEAT BACK AIR BAG HI CTRL PASS SEAT BACK AIR BAG LO CTRL PASS SEAT BELT LOAD LIMITER HI CTRL PASS SEAT BELT LOAD LIMITER LO CTRL PASS SEAT BELT SW SIG PASSENGER FRONT SEAT OUTBOARD SEAT BACK AIR BAG PASSENGER SEAT BELT SWITCH PASSENGER FRONT SEAT BELT BUCKLE PYROTECHNIC BATTERY CUT-OFF ACTUATOR REAR CENTER SEAT BELT BUCKLE REAR MIDDLE SEAT BELT SWITCH REAR CENTER SEAT BELT SW SIG RESTRAINTS CONTROL MODULE (REAR OF FLOOR CONSOLE) RF ROOF RAIL AIR BAG HI CTRL RF ROOF RAIL AIR BAG LO CTRL RF SIDE IMPACT SENS LO REF RF SIDE IMPACT SENS SIG RIGHT QUARTER PANEL EXTENSION AIR BAG SIDE IMPACT REAR SENSOR RIGHT REAR SEAT BELT BUCKLE RIGHT REAR SEAT BELT SWITCH RR SEAT BELT PRETENSIONER CTRL RR SEAT BELT PRETENSIONER LO CTRL RR SEAT BELT SW SIG RR SIDE IMPACT SENS LO REF RR SIDE IMPACT SENS SIG VIO/ORG WIRE WHT/ORG WIRE YEL/ORG WIRE
