Cadillac Lyriq I (2022-2024) left front side door sill plate illumination Wiring diagram
This page shows the only wiring diagram for the component.left front side door sill plate illumination, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front side door sill plate illumination (1 of 1)
BLK WIRE
BLU/GRN WIRE
DRIVER FRONT SIDE DOOR COURTESY LAMP
FRONT FLOOR CONSOLE COMPARTMENT LAMP
GRN/GRY WIRE
GRN/VIO WIRE
GRY WIRE
INSTRUMENT PANEL COMPARTMENT LAMP
LEFT FRONT SIDE DOOR SILL PLATE ILLUMINATION
LEFT REAR CARGO CENTER COURTESY LAMP
LEFT REAR SIDE DOOR COURTESY LAMP
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LIFTGATE COURTESY LAMP
NCA WIRE
PASSENGER FRONT SIDE DOOR COURTESY LAMP
RIGHT FRONT SIDE DOOR SILL PLATE ILLUMINATION
RIGHT REAR CARGO CENTER COURTESY LAMP
RIGHT REAR SIDE DOOR COURTESY LAMP
VIO/GRY WIRE
WHT/VIO WIRE
Go to component -> Courtesy lamps circuit (2 of 5) -> LEFT FRONT SIDE DOOR SILL PLATE ILLUMINATION
