Cadillac Lyriq I (2022-2024) lamp feedback signal Wiring diagram
This page shows the only wiring diagram for the component.lamp feedback signal, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamp feedback signal (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CENTER HIGH MOUNTED
CHARGE PORT DOOR
CHARGE PORT HOUSING
CHARGE PORT HOUSING LAMP
COMPUTER DATA LINES SYSTEM
GRN/BRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LAMP CONTROL
LAMP ENABLE SIGNAL
LAMP FEEDBACK SIGNAL
LED CONTROL
LEFT FRONT PARK
LEFT FRONT SIDE MARKER LAMP
LEFT TURN SIGNAL LIGHT
LIGHTING CONTROL MODULE (LEFT SIDE OF DASH)
NCA WIRE
PARK LIGHTS
REAR TURN SIGNAL
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP LED DRIVER MODULE
RIGHT REAR FASCIA SIGNAL LAMP
RIGHT REAR FASCIA SIGNAL LAMP LED DRIVER MODULE
RIGHT REAR TRAILER STOP/
RIGHT REAR TURN SIGNAL
RIGHT TURN SIGNAL LIGHT
SEQUENTIAL TURN
STOP LAMP
STOP LAMP SUPPLY VOLTAGE
TRAILER TOW CIRCUIT
TURN LAMP CONTROL
VIO/BLK WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (4 of 6) -> LAMP FEEDBACK SIGNAL
