Cadillac Lyriq I (2022-2024) headlamp leveling system wiring diagram
This page shows the only wiring diagram for the component.headlamp leveling system, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
headlamp leveling system wiring diagram (1 of 1)
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
CAN-BUS
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT AXLE LEVEL SENS LOW REFERENCE
FRONT SUSPENSION AUTOMATIC FORWARD LIGHTING POSITION SENSOR
FRONT VEHICLE LEVEL
FRONT VEHICLE LEVEL SENSOR SIGNAL
HEADLAMP CONTROL MODULE
HEADLAMP LEVELING SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FRONT HEADLAMP
LEFT HEADLAMP LED DRIVER MODULE
REAR SUSPENSION AUTOMATIC FORWARD LIGHTING LEVELING POSITION SENSOR
RED/BRN WIRE
RIGHT END OF DASH)
RIGHT FRONT HEADLAMP
RIGHT HEADLAMP LED DRIVER MODULE
VEHICLE LEVEL CONTROL
VEHICLE LEVEL CONTROL POS SENS SIG
VEHICLE LEVEL CTRL POS SENS LOW REF
VIO/BLK WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Headlamps leveling circuit -> HEADLAMP LEVELING SYSTEM
