Cadillac Lyriq I (2022-2024) driver monitoring camera Wiring diagram
This page shows the only wiring diagram for the component.driver monitoring camera, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver monitoring camera (1 of 1)
3-WH DRIVER MONITORING SYS CAMERA LVDS SIG
4-WH
BATT POS VOLT
BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BUS (-) 2 SERIAL DATA
COAX
COMPUTER DATA LINES SYSTEM
DRIVER ILL LAMP 1 CTRL
DRIVER ILL LAMP 2 CTRL
DRIVER ILL LAMP GROUND
DRIVER MONITORING CAMERA
GROUND
HOT AT ALL TIMES
IMAGE PROCESSING MODULE (ABOVE LEFT REAR WHEELWELL)
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOGIC
NCA WIRE
RED/WHT WIRE
RIGHT END OF DASH)
STEERING WHEEL AIR BAG COIL
STEERING WHEEL LED DISPLAY
WHT WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Driver monitoring system circuit -> DRIVER MONITORING CAMERA
