Cadillac Lyriq I (2022-2024) charge port housing charge port door release switch Wiring diagram
This page shows the only wiring diagram for the component.charge port housing charge port door release switch, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charge port housing charge port door release switch (1 of 1)
ACTIVE GRILLE AIR SHUTTER ACTUATOR 1
AIR CONDITIONING EVAPORATOR ELECTRONIC EXPANSION VALVE
BATTERY
BATTERY CHARGER
BATTERY CHARGER 2 BATTERY CHARGER CONTROL MODULE 2
BATTERY CHARGER COUPLER
BATTERY MONITOR MODULE
BLK WIRE
BRAKE MASTER CYLINDER)
BRAKE SYSTEM CONTROL MODULE
CHARGE PORT HOUSING CHARGE PORT DOOR RELEASE SWITCH
COOLING FAN MOTOR
ENGINE COMPARTMENT COVER SWITCH
EXTERNAL AIR CONDITIONING CONDENSER REFRIGERANT FLOW VALVE
FRONT GRILLE ILLUMINATED EMBLEM
FRONT GRILLE ILLUMINATION LAMP
GRN WIRE
HEATED WINDSHIELD RELAY
HEATER AIR CONDITIONING CONDENSER REFRIGERANT FLOW VALVE
HORN
INSTRUMENT PANEL COMPARTMENT DOOR LATCH ACTUATOR RELAY
LEFT FOLDING REAR SEAT BACK RELAY
LEFT FRONT HEADLAMP LEFT HEADLAMP LED DRIVER MODULE
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
NCA WIRE
PARKING LAMP RELAY
POWER STEERING CONTROL MODULE
REAR WINDOW DEFOGGER RELAY
RIGHT FOLDING REAR SEAT BACK RELAY
RIGHT FRONT HEADLAMP RIGHT HEADLAMP LED DRIVER MODULE
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RWD
TRAILER BACKUP LAMP RELAY
TRANSMISSION PARK POSITION RELAY
VIDEO DISPLAY INSIDE REAR VIEW MIRROR CAMERA WASHER FLUID PUMP RELAY
W/O FULL VIDEO DISPLAY
WINDSHIELD WASHER PUMP
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WASHER SOLVENT CONTAINER LEVEL SENSOR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MOTOR RELAY
Go to component -> Ground distribution circuit (1 of 8) -> CHARGE PORT HOUSING CHARGE PORT DOOR RELEASE SWITCH
