Cadillac Lyriq I (2022-2024) body ctrl mod lin bus 13 Wiring diagram
This page shows the only wiring diagram for the component.body ctrl mod lin bus 13, which is found in the car Cadillac Lyriq I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body ctrl mod lin bus 13 (1 of 1)
BATT POS VOLT
BLK WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BODY CTRL MOD LIN BUS 13
BRN/YEL WIRE
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT PEDESTRIAN ALERT SOUND SPEAKER
GRN/GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
PEDESTRIAN ALERT CONTROL MODULE
PEDESTRIAN ALERT SOUND SPKR (-) CTRL
PEDESTRIAN FRIENDLY ALERT SPEAKER 2 (-) CTRL
REAR PEDESTRIAN ALERT SOUND SPEAKER
RED/YEL WIRE
VIO/BRN WIRE
Go to component -> Pedestrian protection system circuit -> BODY CTRL MOD LIN BUS 13
