Cadillac Eldorado X (1992-2002) windshield wiper switch Wiring diagrams

ACCESSORY RELAY BLK WIRE COVER) DK BLU WIRE DK GRN WIRE FUSE GRY WIRE HIGH LOW HIGH LOW MIN HOT AT ALL TIMES HOT IN ACCY, RUN INSTRUMENT CLUSTER SYSTEM MAX MIN MIST OFF MIST OFF LOW MIN MAX MIST OFF MAX NCA WIRE OFF ORG/ WIRE PARK SWITCH PNK WIRE PPL REAR FUSE BLOCK (LEFT FRONT OF REAR COMPARTMENT, ON ELECTRONICS BAY) RED WIRE SOLID STATE UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT, NEAR STRUT TOWER) WASH WASHER SWITCH WHT WIRE WINDSHIELD WASHER PUMP (BEHIND LEFT FRONT FASCIA, AT WASHER RESERVOIR) WINDSHIELD WIPER SWITCH WINDSHIELD WIPER/WASHER MODULE (ON LEFT SIDE OF FIREWALL, IN ENGINE COMPARTMENT) WIPER MOTOR WIPERS FUSE YEL WIRE

24,000 OHMS ACCESSORY RELAY BLK WIRE COVER) DK BLU WIRE DK GRN WIRE FUSE GRN WIRE GRY WIRE HIGH LOW MIN HOT AT ALL TIMES HOT IN ACCY, RUN INSTRUMENT CLUSTER SYSTEM LOW MIN LOW/WASH BATTERY GROUND DELAY INPUT HIGH CTRL 43 1051 94 LT BLU WIRE LT GRN WIRE MAX MIST OFF MIST OFF MAX NCA WIRE OFF ORG/ WIRE OUTSIDE MOISTURE SENSOR (NEAR REARVIEW MIRROR) PARK SWITCH PNK WIRE PPL REAR FUSE BLOCK (LEFT FRONT OF REAR COMPARTMENT, ON ELECTRONICS BAY) RED WIRE SOLID STATE WASH WASHER SWITCH WINDSHIELD WASHER PUMP (BEHIND LEFT FRONT FASCIA, AT WASHER RESERVOIR) WINDSHIELD WIPER SWITCH WINDSHIELD WIPER/WASHER MODULE (ON LEFT SIDE OF FIREWALL, IN ENGINE COMPARTMENT) WIPER MOTOR WIPERS FUSE YEL WIRE
