Cadillac Eldorado X (1992-2002) ignition switch Wiring diagrams
This page contains all the electrical diagrams for the component. ignition switch, in which he is found in the car Cadillac Eldorado X (1992-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ignition switch wiring diagram (1 of 2)
ACCESSORY RELAY
AMP FUSE
BLK WIRE
BLOWER MOTOR
BODY 3 FUSE
BODY CONTROL MODULE (PZM)
BODY CONTROL MODULE (PZM) ELECTRONIC PRNDL
BODY CONTROL MODULE (PZM) INSIDE REAR VIEW MIRROR
BRN WIRE
BULB TEST
BULB TEST LOCK LOCK OFF OFF
COMFORT FUSE
CONTINUOUSLY VARIABLE ROAD SENSING SUSPENSION (CVRSS) MODULE
CRANK FUSE
DATA LINK CONNECTOR (DLC)
DRL FUSE
DRL RELAY
FOG FUSE
FOG LAMP RELAY
FROM BATT 2 FUSE (DIAGRAM 2 OF 5)
FROM BODY FUSE 2 (DIAGRAM 1 OF 5)
FROM IGNITION SWITCH (DIAGRAM 2 OF 5)
FUSE
HAZARD FLASHER
HAZARD FUSE
HDLPS FUSE
HEADLAMP DIMMER SWITCH
HEADLAMP RELAY
HEATER, A/C PROGRAMMER
IGN 0 (ENG) FUSE ABS FUSE
IGNITION SWITCH
IGNO- BODY FUSE
INADVERT FUSE
INADVERTENT POWER RELAY
INSTRUMENT CLUSTER
LAMPS FUSE
LEFT BOSE RELAY (IF EQUIPPED)
LEFT UNDERHOOD FUSE BLOCK
LOCK OFF
LT BLU WIRE
LT GRN WIRE
MIRROR FUSE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OUTSIDE MOISTURE SENSOR
OUTSIDE REAR VIEW MIRROR SWITCH MEMORY MIRROR MODULE (MMM)
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) ELECTRONIC BRAKE CONTROL MODULE (EBCM)
PPL
REAR COMPARTMENT FUSE BLOCK
REAR COMPARTMENT RELAY CENTER 1
REAR COMPARTMENT RELAY CENTER 2
REAR DEFOG RELAY ELC RELAY CLIMATE CONTROL PANEL (CCP)
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE COMPACT DISC (CD) PLAYER
RIGHT BOSE RELAY (IF EQUIPPED)
RSS FUSE
RUN WIRE
STOP FUSE
STOPLAMP/ A/T SHIFT LOCK CONTROL SWITCH
TO CONT PWR BKUP RELAY (DIAGRAM 4 OF 5)
TO CONTROLLED POWER RELAY (DIAGRAM 4 OF 5)
TO IGN 1 FUSE (DIAGRAM 4 OF 5)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 5 OF 5)
UNDERHOOD FUSE BLOCK
UNDERHOOD RELAY CENTER
W/ CHASSIS CONTINUOUS VALVE REAL TIME DAMPING
W/CHASSIS CONTINUOUS VALVE REAL TIME DAMPING
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> IGNITION SWITCH
ignition switch wiring diagram (2 of 2)
BATT 1 FUSE
BATT 2 FUSE
BLK WIRE
BULB TEST LOCK OFF
CRANK FUSE
GROUND DISTRI- BUTION SYSTEM
HOLD- IN COIL PULL- IN COIL
HOT AT ALL TIMES
HOT IN RUN
IGNITION POSITIVE VOLTAGE
IGNITION SWITCH
NCA WIRE
PNK WIRE
POWER DISTRI- BUTION SYSTEM
PPL
RED WIRE
RELAY COIL OUTPUT
RIGHT UNDERHOOD FUSE BLOCK (IN LEFT OF ENGINE COMPARTMENT)
RUN WIRE
STARTER MOTOR
STARTER SOLENOID BATTERY
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT)
UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT) OXY SEN 2 FUSE
YEL WIRE
Go to component -> Starting circuit -> IGNITION SWITCH
