Cadillac Eldorado X (1992-2002) computer data lines ststem wiring diagram
This page shows the only wiring diagram for the component.computer data lines ststem, which is found in the car Cadillac Eldorado X (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
computer data lines ststem wiring diagram (1 of 1)
55 31 68 FAN CTRL COOL TEMP SW SENSOR GROUND 410 718
A/C COMP FUSE
A/C COMPRESSOR CLUTCH RELAY (IN ENGINE COMPARTMENT FUSE/RELAY BLOCK)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES STSTEM
COOL FANS FUSE
DK BLU WIRE
DK GRN WIRE
ENGINE COMPARTMENT FUSE/RELAY CENTER
ENGINE COOLING FAN 1 RELAY (REARWARD OF RADIATOR)
ENGINE COOLING FAN 2 RELAY (REARWARD OF RADIATOR)
ENGINE COOLING FAN 3 RELAY (REARWARD OF RADIATOR)
HOT AT ALL TIMES
HOT IN RUN, START
LEFT COOLING FAN MOTOR
LT BLU WIRE
ORG/ WIRE
PPL DATA LINE FAN CTRL
RED WIRE
RIGHT MAXI FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> COMPUTER DATA LINES STSTEM
