Cadillac DTS I (2005-2011) Electronic damper control circuit

2501 2501 COMPUTER DATA LINES SYSTEM AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR (NEAR REAR AUTOMATIC LEVEL CTRL RLY BLK WIRE CLASS 2 SERIAL DATA COMP RELAY FUSE 24 COMPUTER DATA LINES SYSTEM DAMPER SOLENOID (RIGHT FRONT SHOCK ASSEMBLY) DK GRN WIRE DK GRN/GRY WIRE DRIVER INFORMATION CENTER (DIC) ELECTRONIC SUSPENSION CONTROL (ESC) MODULE (RIGHT SIDE OF TRUNK) FRONT SHOCK ASSEMBLY) GMLAN SERIAL DATA BUS+ GMLAN SERIAL DATA BUS- GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT SUSPENSION DAMPER SOLENOID (LEFT LEFT FRONT SUSPENSION POSITION SENSOR (NEAR LEFT FRONT STRUT) LEFT REAR SUSPENSION DAMPER SOLENOID (LEFT REAR SHOCK ASSEMBLY) LEFT REAR SUSPENSION POSITION SENSOR (NEAR LEFT REAR STRUT) LEVEL COMP FUSE 47 LEVEL COMP RELAY 53 LOGIC LT BLU WIRE LT BLU/BLK WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MDL-RTD FUSE 15 NCA WIRE ORG/WHT WIRE ORG/YEL WIRE PNK/DK GRN WIRE PPL PPL/BLK WIRE PPL/WHT WIRE REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/WHT WIRE RIGHT FRONT SUSPENSION POSITION SENSOR (NEAR RIGHT FRONT STRUT) RIGHT REAR SUSPENSION DAMPER SOLENOID (RIGHT REAR SHOCK ASSEMBLY) RIGHT REAR SUSPENSION POSITION SENSOR (NEAR RIGHT REAR STRUT) SUSPENSION CARRIER) TAN WIRE TAN/BLK WIRE TAN/DK BLU WIRE TAN/DK GRN WIRE TAN/GRY WIRE TAN/ORG WIRE TAN/VIO WIRE TAN/WHT WIRE VIO WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE
