Cadillac DTS I (2005-2011) w/ auxiliary folding seat Wiring diagram

1-2 SHIFT SOLENOID (SS) VALVE A 2-3 SHIFT SOLENOID (SS) VALVE B 8 46 33 53 REVERSE LOCKOUT PARK/NEUTRAL SIG SERIAL DATA BUS - SERIAL DATA BUS + ACC WAKE-UP SERIAL DATA AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (ISS) SENSOR AUTOMATIC TRANSMISSION SHIFT LEVER BATTERY BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU/WHT WIRE DK GRN WIRE ECM/TCM FUSE 5 ENGINE CONTROL MODULE (ECM) GROUND GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES REAR FUSE BLOCK (UNDER LEFT REAR SEAT) HOT IN RUN OR START HOT W/ RUN RELAY 64 ENERGIZED ISS LOW SIGNAL LT BLU/WHT WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL OSS LOW SIG PC SOL VLV LO CTRL PRESSURE CONTROL (PC) SOLENOID VALVE RANGE SW SIG A LOW REFERENCE IGNITION 1 VOLT BATT POSITIVE VOLT RANGE SW SIG B RANGE SW SIG C RED WIRE RED/WHT WIRE REVERSE LOCKOUT SOLENOID RUN 2 FUSE 10 RUN IGNITION 3 VOLT SERIAL DATA BUS (+) SERIAL DATA BUS (-) SOL VALVE CTRL B TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TFT SENSOR SIG TORQUE CONVERTER CLUTCH (TCC) SOLENOID VALVE TRANS/ IGN 1 FUSE 8 TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT STRUT TOWER) TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR TRANSMISSION INTERNAL MODE SWITCH (IMS) UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) W/ AUXILIARY FOLDING SEAT W/ CLIMATE CONTROL SEAT W/ FRONT BUCKET, LUXURY SEAT W/O CLIMATE CONTROL SEAT WHT WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE
