Cadillac DTS I (2005-2011) sunshade sw wiring diagram
This page shows the only wiring diagram for the component.sunshade sw, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sunshade sw wiring diagram (1 of 1)
1 2 3 4 5 6 ACCESSORY VOL GROUND
1 2 SUNSHADE ACTUATOR SUNSHADE ACTUATOR
BLK WIRE
DK BLU WIRE
GRY WIRE
HOT W/ RAP-HC RELAY ENERGIZED
ORG/ WIRE
ORG/BLK WIRE
RAP 2 FUSE 33
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
REAR WINDOW SUNSHADE MODULE (UNDER CENTER OF REAR PACKAGE TRAY)
REAR WINDOW SUNSHADE MOTOR
REAR WINDOW SUNSHADE SWITCH
SUNSHADE SW
YEL WIRE
Go to component -> Rear window sun shade circuit -> SUNSHADE SW
