Cadillac DTS I (2005-2011) right side object sensor (w/ obstacle detection side indicator) wiring diagram
This page shows the only wiring diagram for the component.right side object sensor (w/ obstacle detection side indicator), which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right side object sensor (w/ obstacle detection side indicator) wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 OBJ SENSOR SPLY VOLT
BATT SERIAL DATA SERIAL DATA GND GND
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTER AMBER INDICATOR CTRL
COMPUTER DATA LINES SYSTEM
DK BLU/TAN WIRE
DK GRN WIRE
DK GRN/TAN WIRE
DRIVER DOOR MODULE (DDM)
DRIVER OUTSIDE REARVIEW MIRROR (DRIVER'S DOOR)
FRONT PASSENGER DOOR MODULE (FPDM)
FRONT, REAR OBJECT ALARM MODULE (RIGHT FRONT OF TRUNK)
GRY/BRN WIRE
INDICATOR CTRL
INFORMATION CENTER TELLTALE ASSEMBLY
LED CONTROL
LEFT AMBER INDICATOR CTRL
LEFT FRONT CORNER OBJECT ALARM SENSOR (LEFT CORNER OF FRONT BUMPER)
LEFT FRONT MIDDLE OBJECT ALARM SENSOR (LEFT MIDDLE OF FRONT BUMPER)
LOW SPEED SERIAL DATA
ORG/BLK WIRE
PASSENGER OUTSIDE REARVIEW MIRROR (FRONT PASSENGER'S DOOR)
PNK LED SIGNAL WIRE
PNK WIRE
PNK/BLK WIRE
PPL/BLK WIRE
PPL/WHT WIRE
RED IND CTRL WIRE
RED WIRE
RED/WHT WIRE
RF MIDDLE OBJ SENS SIG RF CORNER OBJ SENS SIG
RIGHT FRONT CORNER OBJECT ALARM SENSOR (RIGHT CORNER OF FRONT BUMPER)
RIGHT FRONT MIDDLE OBJECT ALARM SENSOR (RIGHT MIDDLE OF FRONT BUMPER)
RIGHT SIDE OBJECT SENSOR (W/ OBSTACLE DETECTION SIDE INDICATOR)
TELLTALE ASSEMBLY
WHT WIRE
Go to component -> Parking assistant circuit (2 of 2) -> RIGHT SIDE OBJECT SENSOR (W/ OBSTACLE DETECTION SIDE INDICATOR)
